Airtac NPM Clamp Cylinder NPM35T63X13B
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13B Knife-Edge Cylinder Specifications
- Model: NPM35T63X13B
- Type: Compact ISO/VDMA standard knife-edge cylinder
- Bore size: Ø35mm
- Stroke: 63mm
- Operating pressure: 0.05–0.9 MPa
- Cushioning: Fixed cushion (dual-side adjustable optional)
- Mounting style: Square body with ISO/VDMA mounting patterns
- Port size: 1/4" NPT (G1/8 optional)
- Operating temperature: -20℃ to 80℃
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: Polyurethane (NBR available on request)
- Weight: 1.8kg (excluding accessories)
- Dimensions: 210mm(L) × 35mm(W) × 35mm(H) (full extension)
- Rod thread: M12×1.25 (male)
- Max theoretical force: 962N @0.63MPa (extending)
- Piston speed: 50–800mm/s
- ISO standard: 15552
Precision-engineered knife-edge cylinder optimized for space-constrained automation systems. Features wear-resistant nickel-plated guide rings and dual dust wipers for contaminant exclusion. The symmetrical square body design enables multi-position mounting with optional magnetic sensor grooves (model variant: NPM35T63X13B-M). Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- CNC machine tool clamping/unclamping mechanisms
- Printing press paper feed systems
- Robotic welding fixture positioning
- High-speed packaging machine pusher arms
- Semiconductor wafer handling robots
Installation guidelines:
Maintain 0.5–1mm clearance between cylinder body and machine frame for thermal expansion.
Use dynamic load calculations when stroke exceeds 50mm. Lubricate through air line with
oil mist of 1–2 drops/m³. Maximum side load: 30N at full extension.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13B |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
