Airtac NPM Clamp Cylinder NPM35T63X13BI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13BI Blade Cylinder Technical Specifications
- Model: NPM35T63X13BI
- Type: Compact precision blade cylinder (double-acting)
- Bore size: Ø35mm
- Stroke: 63mm
- Operating pressure: 0.05–0.9 MPa
- Piston speed: 50–700 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting style: BI-type (rear pivot base with front flange)
- Cushioning: Adjustable air cushion (both ends)
- Port size: M5x0.8 (standard) / NPT1/8 (optional)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU hybrid seals
- Weight: 1.23 kg (without accessories)
- Dimensions: 200mm(L) × 58mm(W) × 48mm(H) (max extended length)
- Rod end type: Female thread M10x1.25
- Position detection: Magnet embedded (SM/SD sensor compatible)
- Protection rating: IP54 (standard) / IP67 (optional wiper upgrade)
High-precision blade cylinder featuring anti-rotation mechanism and integrated guide rails, optimized for vertical mounting applications requiring strict positional accuracy (±0.1mm repeatability). The T-slot mounting surface allows direct tooling plate attachment, while the hardened steel blade prevents lateral deflection under load. Includes wear-compensation seals for extended maintenance intervals.
- CNC tool changers in machining centers
- Precision clamping in semiconductor wafer handling
- Vertical lifting mechanisms in automated assembly lines
- Positioning gates in high-speed sorting systems
- Material stop devices in progressive die stamping
Installation note:
Lubricate guide rails with ISO VG32 hydraulic oil before initial operation.
For vertical installations exceeding 45° angle, install external rod support brackets
when cycle rate exceeds 30 CPM. Maximum side load capacity: 85N at full extension.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13BI |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
