Airtac NPM Clamp Cylinder NPM35T63X13BIL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13BIL Blade Cylinder Specifications
- Model: NPM35T63X13BIL
- Type: Guided rodless cylinder with integrated blade clamp
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.1–0.9 MPa
- Double-acting operation
- Cushioning: Adjustable pneumatic cushion (X13 variant)
- Mounting: Standard foot-mount with lateral blade interface (BIL suffix)
- Port size: M5x0.8 (dual ports)
- Seal material: NBR with wear-resistant scraper
- Temperature range: -20℃ to 80℃
- Weight: 1.65kg (with mounting accessories)
- Dimensions: 213mm(L) × 56mm(W) × 35mm(H)
- Piston rod hardness: HRC 50-55 chromed surface
- Repeat positioning accuracy: ±0.1mm
- Max lateral load: 18N
Precision-guided rodless cylinder featuring a hardened blade-style coupling interface for tooling applications. The T-slot blade design enables rapid tool changes with 4-point clamping security. Anti-rotation mechanism maintains ±0.05° angular accuracy under load. Integrated scraper prevents debris ingress in high-particulate environments.
- CNC machine tool automatic changer systems
- Semiconductor wafer handling robots
- Automotive welding fixture positioning
- High-speed sorting mechanisms with quick-connect end effectors
- Precision grinding machine workholding
Installation notes:1. Align blade interface within 0.2mm parallelism tolerance during mounting
2. Use ISO 8573-1 Class 3 compressed air with 5-10μm filtration
3. Apply light machine oil (ISO VG32) monthly to lubrication ports
4. Avoid continuous side loading beyond 50% of rated capacity
| Property | Property Value |
|---|---|
| sku | NPM35T63X13BIL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
