Airtac NPM Clamp Cylinder NPM35T63X13BL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13BL Tool Clamping Cylinder Specifications
- Model: NPM35T63X13BL
- Type: Double-acting linear guide cylinder (ISO 15552 compliant)
- Bore size: Ø35 mm
- Stroke: 63 mm
- Operating pressure: 0.1–0.9 MPa
- Cushioning: Adjustable hydraulic shock absorber
- Mounting type: BL series - front flange with tapped holes
- Port size: M5x0.8 (G1/8 adapter optional)
- Piston rod material: Hard chrome-plated steel (HRC 45-50)
- Cylinder tube: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: 1.85 kg (±2%)
- Dimensions: 200mm(L) × 64mm(W) × 64mm(H)
- Repeat accuracy: ±0.05 mm
- Max thrust: 360N @ 0.6MPa
- Protection rating: IP54 (standard wiper)
High-precision linear guide cylinder with integrated ball bearing system, engineered for CNC tool changing applications. Features dual anti-rotation guides (X-axis and Y-axis) for exceptional lateral load resistance. The T-slot mounting interface enables rapid installation alignment. Requires ISO VG32 hydraulic oil lubrication for optimal performance.
- Automatic tool changers in machining centers
- Precision clamping systems for CNC routers
- Robotic arm end-effector positioning
- Semiconductor wafer handling equipment
- Optical lens polishing machinery
Maintenance tip:
Lubricate guide rails every 500,000 cycles using lithium soap grease (NLGI #2).
Avoid side impact forces exceeding 150N during operation.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13BL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
