Airtac NPM Clamp Cylinder NPM35T63X13C
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13C Knock Cylinder Specifications
- Model: NPM35T63X13C
- Type: Compact square-type knock cylinder
- Bore size: Ø35mm
- Stroke: 63mm
- Knock pin size: Ø13mm
- Operating pressure: 0.1–0.9 MPa
- Mounting style: Front flange with through holes
- Cushioning: Adjustable air cushion (both ends)
- Material: Aluminum alloy body, hardened steel piston rod
- Seal type: NBR seals with wear-resistant ring
- Temperature range: -10℃ to 70℃
- Port size: Rc1/4 (ISO G1/4 optional)
- Weight: 1.25kg ±2%
- Dimensions: 200mm(L) × 80mm(W) × 80mm(H)
- Rod thread: M12×1.25
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision knock cylinder designed for precision positioning and mechanical tool changes. Features double piston seals for leak-free operation and chrome-plated piston rod for corrosion resistance. The compact square profile allows direct mounting in tight machine spaces. Includes shock-absorbing cushions for smooth end-stroke deceleration.
- CNC machine tool automatic tool changers
- Precision indexing mechanisms
- Robotic arm positioning locks
- Semiconductor wafer handling systems
- Stamping press die height adjustment
Installation note:
Align knock pin within 0.05mm tolerance during assembly. Use steel washers under mounting bolts to prevent aluminum thread deformation. For vertical installations, install air exhaust mist separator to prevent lubricant drainage.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13C |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC 110V |
| Hydraulic Cylinder Bore | 63mm |
