Airtac NPM Clamp Cylinder NPM35T63X13CI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13CI Blade Cylinder Specifications
- Model: NPM35T63X13CI
- Type: Double-acting linear blade cylinder
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Temperature range: -10℃ to 80℃
- Port size: M5x0.8 (standard)
- Mounting type: CI series (ISO 15552 front flange)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (nitrile rubber)
- Protection rating: IP54 (standard wiper design)
- Weight: 1.3kg ±2%
- Dimensions: 250mm (Length) × 57mm (Width) × 57mm (Height) (including mounting accessories)
- Sensor compatibility: M9/M12 proximity switches (optional groove)
High-precision blade cylinder engineered for rapid tool clamping applications, featuring a compact profile with dual anti-rotation guides for enhanced stability. The T-slot piston design delivers 15% faster response times compared to standard cylinders. Includes integrated cushioning adjustment screws and wear-resistant scraper seals for debris protection.
- CNC machining center tool changers
- Automated drilling/riveting stations
- Robotic gripper positioning systems
- Precision stamping equipment
- Semiconductor wafer handling robots
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Avoid side-load forces exceeding 20N·m. For vertical mounting,
use locknut (ANL-12) to prevent unintended rotation.
Recommended maintenance interval: 5 million cycles or 12 months.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13CI |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC 110V |
| Hydraulic Cylinder Bore | 63mm |
