Airtac NPM Clamp Cylinder NPM35T63X13E
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13E Rodless Cylinder Technical Details
- Model Code: NPM35T63X13E
- Type: Compact guided rodless cylinder (ISO 15552 compliant)
- Bore size: Ø35 mm (±0.1mm manufacturing tolerance)
- Stroke: 63 mm (adjustable stroke stopper optional)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Dual adjustable rubber buffers
- Ambient temperature: -20℃ to 80℃ (NBR seals)/150℃ max with HS seal kit
- Piston speed: 50–800 mm/s (lubricated operation)
- Mounting: Standard MF1/MF2 profile & multi-position tapped holes
- Material: Aluminum alloy barrel (hard anodized), CR12MoV piston rod
- Weight: 1.65 kg (excluding accessories)
- Dimensions: 204mm(L) × 58mm(W) × 48mm(H) (full retraction)
- Port size: M5x0.8 (1/8 NPT adaptor available)
- Repeat accuracy: ±0.1mm (with guide mechanism)
- Protection class: IP54 (standard)/IP67 with wiper upgrade
Precision linear actuator featuring integrated T-slot guide rails for moment load resistance. The anti-rotation design maintains positional accuracy during high-cycle operations. Pre-loaded ball bearings ensure smooth travel across 10 million cycle rating. Compatible with magnetic sensors (D-M9N series recommended).
- PCB depaneling machines (stiffness prevents component misalignment)
- Automated pharmaceutical blister packaging lines
- Glass panel transfer systems (low particle generation design)
- Semiconductor wafer handling robots
- Vertical CNC tool changers (optimized for Z-axis movements)
Maintenance protocol:
Relubricate every 5,000km cumulative travel using ISO VG32 turbine oil.
Avoid side load exceeding 15N·m. For vertical installations, use counterbalance valves (AVSC-08 accessory kit required).
| Property | Property Value |
|---|---|
| sku | NPM35T63X13E |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC24V |
| Hydraulic Cylinder Bore | 63mm |
