Airtac NPM Clamp Cylinder NPM35T63X13EIL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13EIL Blade Cylinder Technical Details
- Model Code: NPM35T63X13EIL
- Bore size: 35mm (ISO standard)
- Stroke: 63mm ±0.5mm tolerance
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-800 mm/s (lubricated)
- Cushioning type: Adjustable elastic buffer
- Mounting style: AX series flange (X13 code)
- Sensor compatibility: M9/M12 inductive (EIL suffix)
- Port size: G1/8 (NPT optional)
- Ambient temperature: -10℃ to 80℃
- Weight: 1.85kg ±3% (without accessories)
- Dimensions: 189mm(L) × 60mm(W) × 60mm(H)
- Rod thread: M10×1.25 (ISO 12240-2)
- Repeat accuracy: ±0.1mm
- Piston material: Hard anodized aluminum alloy
Precision blade-type cylinder optimized for CNC tool changing systems, featuring twin-piston design for enhanced gripping force (up to 320N at 0.5MPa). The "EIL" variant includes integrated magnetic field detection slots for cylinder position feedback. Requires ISO VG32 hydraulic oil mist lubrication for optimal performance.
- Automatic tool changers in machining centers
- Fixture clamping in CNC milling machines
- Robotic arm end-effector positioning
- High-speed punching machine tool holders
- Precision die-casting ejection mechanisms
Installation protocol:
Align within 0.2mm perpendicularity tolerance during mounting.
Use anti-vibration washers on flange bolts (recommended torque 12-15N·m).
Maintain 0.3-0.5MPa air pressure for initial 50 operation cycles.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13EIL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC24V |
| Hydraulic Cylinder Bore | 63mm |
