Airtac NPM Clamp Cylinder NPM35T63X13EL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13EL Rodless Strike Cylinder Specifications
- Model: NPM35T63X13EL
- Type: Compact rodless cylinder with dual-action strike mechanism
- Bore size: 35mm
- Stroke: 63mm
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable rubber buffers (front/rear)
- Mounting style: Dual side lug mounts with M6x1.0 threads
- Port size: M5x0.8 (standard), G1/8 optional
- Operating temperature: -10℃ to 80℃
- Piston material: Aluminum alloy with hard anodized coating
- Seal type: NBR wear-resistant seals
- Repeat accuracy: ±0.2mm
- Weight: 1.2kg (excluding accessories)
- Dimensions: 216mm(L) × 56mm(W) × 56mm(H) (fully retracted)
- Protection class: IP54 (standard), IP67 with optional wipers
- Max thrust: 318N @ 0.63MPa
Precision-engineered rodless cylinder featuring a unique internal stripper mechanism for tool ejection applications. The T-slot guided piston design ensures smooth linear motion with minimal lateral deflection. Enhanced dust resistance and optional magnetic piston for sensor compatibility. Requires ISO 8573-1:2010 Class 3 compressed air.
- CNC machine tool changers (ATC systems)
- PCB drilling/spindle positioning units
- Laser cutting machine material clamps
- Automated deburring/punching stations
- Semiconductor wafer handling robots
Installation note:
Lubricate with ISO VG32 pneumatic oil during initial setup.
For vertical mounting, use auxiliary guide rails to prevent side load.
Minimum 2mm clearance required between cylinder body and machine structure.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13EL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | AC24V |
| Hydraulic Cylinder Bore | 63mm |
