Airtac NPM Clamp Cylinder NPM35T63X13FI
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13FI Knife Edge Cylinder Specifications
- Model: NPM35T63X13FI
- Series: NPM (Compact Guided Cylinder)
- Bore size: 35mm
- Stroke: 63mm
- Mounting type: FI series flange (front flange with integrated guide)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Piston rod material: Hard chrome-plated steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 1.45 kg (with rod)
- Dimensions:
- Length (retracted): 162mm
- Width (flange): 60mm
- Height (including guide): 80mm
- Mounting hole spacing: 25mm × 25mm
- Rod end type: Female thread M12×1.25
- Lubrication: Pre-lubricated (oil-free operation possible)
High-precision guided cylinder with integrated knife-edge guide mechanism, designed for applications requiring exceptional lateral load capacity and precise linear motion. Features dual adjustable cushions for smooth deceleration and a wear-resistant guide system with adjustable preload. The FI flange mounting allows direct installation in confined spaces while maintaining structural rigidity.
- CNC tool changers in machining centers
- Precision clamping fixtures for EDM machines
- Automated sorting gate actuators
- Semiconductor wafer handling systems
- Laser cutting head positioning mechanisms
Installation note:
Maintain perpendicularity within 0.1mm/m during mounting. Use mounting torque of 5.4-6.6 N·m for M5 screws.
For high-cycle applications (>1 million cycles), implement regular guide rail lubrication every 500,000 cycles.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13FI |
| Output Force | Output Force 3.5 ton |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC12V |
| Hydraulic Cylinder Bore | 63mm |
