Airtac NPM Clamp Cylinder NPM35T63X13FIL
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM Series Knife Edge Cylinder NPM35T63X13FIL Technical Details
- Model Code Breakdown: NPM35-T-63-X13-F-I-L
- Bore size: Ø35mm
- Stroke: 63mm
- Rod type: Knife-edge piston (double acting)
- Mounting: Front flange (T-type) with through holes
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion (both ends)
- Ambient temperature: -10℃ to 70℃
- Piston speed: 50–800 mm/s
- Port size: M5x0.8 (standard), G1/8 optional
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal type: NBR + PU combination seals
- Weight: 1.25kg (excluding accessories)
- Dimensions: 191mm(L) × 58mm(W) × 58mm(H)
- ISO Standard: 15552 compliant
- Repeat accuracy: ±0.5mm
Precision knife-edge cylinder with optimized air consumption design (X13 variant), featuring integrated cushioning adjustment and fluorine-resistant seals (F-I-L suffix). The T-type mounting flange enables rigid installation for high moment load applications. Special rod scraping ring prevents debris ingress in dirty environments.
- CNC tool clamping/release mechanisms
- PCB depaneling machine pushers
- Glass cutting equipment actuators
- Automated screw driving stations
- Robotic deburring tool changers
Maintenance tip:
Lubricate every 5 million cycles using ISO VG32 turbine oil.
Avoid side load exceeding 15N during operation. Alignment tolerance: ±0.2mm.
- Rod end: Male thread M12×1.25 (standard), clevis kit optional
- Position detection: Built-in magnet for sensor mounting (I-suffix)
- Special variants: Corrosion-resistant treatment (L-suffix)
| Property | Property Value |
|---|---|
| sku | NPM35T63X13FIL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC12V |
| Hydraulic Cylinder Bore | 63mm |
