Airtac NPM Clamp Cylinder NPM35T63X13FL
$346.59
Regular price
$354.09
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
NPM35T63X13FL
Product type:
Tags:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Specialized sealing materials ensure exceptional leak-tight performance in hydraulic cylinder operation;
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
Installation protocol:
Requires 5μm filtered lubricated air (ISO 8573-1 class 4). For vertical mounting,
use tandem cylinders or counterbalance valves. Lubricate every 3 million cycles
with ISO VG32 hydraulic oil.
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM35T63X13FL Knife Edge Cylinder Technical Details
- Series: NPM High-Precision Compact Cylinder
- Bore size: 35mm (ISO 6432 standard)
- Stroke: 63mm (adjustable with stopper)
- Rod end: FL type - female threaded (M12×1.25)
- Operating pressure: 0.05–1.0 MPa
- Piston speed: 50–800 mm/s
- Cushioning type: Rubber buffer + adjustable hydraulic shock absorber
- Ambient temperature: -10℃ to 70℃
- Mounting: Standard ISO mounting slots (5mm width)
- Port size: M5×0.8 (dual auto switch grooves)
- Material: Aluminum alloy body (hard anodized), CR seals
- Weight: 1.25kg (with rod)
- Dimensions: 188mm(L) × 48mm(W) × 48mm(H)
- Repeat accuracy: ±0.1mm
- Air consumption: 5.7L/stroke (at 0.5MPa)
Precision-engineered knife edge cylinder with integrated shock absorption, optimized for high-speed positioning in confined spaces. Features wear-resistant PTFE rod seals and anti-rotation guide mechanism. The T-slot design allows direct sensor mounting for position feedback.
Industrial Applications:
- CNC machining center tool clamping systems
- PCB drilling machine Z-axis actuators
- Laser cutting equipment material holders
- Automated assembly line positioning jigs
- Semiconductor wafer handling robots
Installation protocol:
Requires 5μm filtered lubricated air (ISO 8573-1 class 4). For vertical mounting,
use tandem cylinders or counterbalance valves. Lubricate every 3 million cycles
with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | NPM35T63X13FL |
| Output Force | Output Force 3.5 ton |
| Micro Switch | 2 Micro Switches |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC12V |
| Hydraulic Cylinder Bore | 63mm |
