Airtac NPM Clamp Cylinder NPM45T63X13B
2、Cylinder barrels undergo precision surface treatments to significantly enhance wear resistance and corrosion durability;
3、Integrated spindle air purge functionality for enhanced machining cleanliness.
Category: Tool Clamping Cylinders | Brand: AirTAC | Series: NPM
AirTAC NPM45T63X13B Twin-Piston Rod Striker Cylinder Specifications
- Model: NPM45T63X13B
- Type: Double-piston rod striker cylinder (non-rotating)
- Bore size: Ø45mm
- Stroke: 63mm (±1mm tolerance)
- Operating pressure: 0.05–0.8 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting: Square flange with 4×M8 threaded holes
- Port size: PT1/4 (G1/4 optional)
- Piston rod thread: M12×1.25 (double-end extended)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, chrome-plated piston rod
- Seal type: NBR + PU combination seals
- Weight: Approx. 2.8kg (without accessories)
- Dimensions: 198mm(L) × 130mm(W) × 130mm(H)
- Shock resistance: ≤1.5m/s² vibration acceleration
- Repeat positioning accuracy: ±0.2mm
High-rigidity striker cylinder designed for precision tool clamping in CNC machining centers. Features dual piston rods for balanced thrust distribution and anti-rotation design maintaining ±0.1° angular accuracy. The hardened chrome piston rod (HRC 45-50) withstands side impacts during tool changes. Includes magnetic sensor slots (NPN/PNP compatible) for position feedback.
- ATC (Automatic Tool Changer) systems in vertical/horizontal machining centers
- High-frequency punching machine tool holders
- Precision die-casting mold clamping mechanisms
- Robotic arm end-effector quick-change systems
- Glass CNC engraving machine spindle locks
Installation notes:
Apply ISO VG32 hydraulic oil or equivalent to air supply (0.3cc/min oil mist).
Avoid lateral loads exceeding 50N. For vertical mounting, use counterbalance valves.
Sensor gap: 1.5mm±0.3mm from magnetic ring.
| Property | Property Value |
|---|---|
| sku | NPM45T63X13B |
| Output Force | Output Force 4500kg |
| Micro Switch | Without Micro Switch |
| Blade Stroke | 13mm |
| Port Size | PT3/8 |
| Standard Voltage | DC24V |
| Hydraulic Cylinder Bore | 63mm |
