Airtac P-3V-M Cover Plate P-3V300M-R2
2、Features centralized intake/exhaust ports and unified wiring layout to streamline troubleshooting processes and enhance maintenance efficiency;
3、Modular design with exceptional flexibility and scalability, allowing arbitrary combination or expansion of connected directional control valves according to operational requirements;
Category: Cover Plates , Brand: Airtac , Series: P-3V-M
AirTAC P-3V-M Cover Plate P-3V300M-R2 Technical Details
- Model: P-3V300M-R2 (End Cover for P-3V-M Series Valves)
- Compatible Valve Series: P-3V-M Modular Solenoid Valves
- Material: A6063-T5 Aluminum Alloy
- Surface Treatment: Hard Anodized (25μm thickness)
- Port Configuration: 3/2-way or 5/2-way manifold mounting
- Seal Type: Integrated NBR O-ring (Shore A 70±5)
- Mounting Pattern: ISO 15407-1 compliant
- Thread Specifications: M5x0.8 Mounting Screws (4 places)
- Pressure Rating: 0.1-1.0 MPa (14.5-145 PSI)
- Temperature Range: -20℃ to 80℃ (Non-freezing conditions)
- Weight: 320g ±5% (Including seals)
- Dimensions: 300mm(L) × 22mm(W) × 18mm(H)
- Protection Class: IP54 (When installed with matched valve body)
Structural end plate designed for modular valve manifold termination, featuring precision-machined alignment pins and leak-proof sealing. The hard-anodized surface resists chemical corrosion and mechanical wear in high-cycle industrial environments. Includes pre-lubricated seals for immediate installation.
- Terminating pneumatic manifold banks in packaging machinery
- Modular assembly lines requiring expandable valve configurations
- Robotic actuator control systems
- Semiconductor manufacturing equipment
- Hydraulic test bench manifold setups
Installation protocol:
Apply 0.5-0.8 N·m torque on mounting screws in cross pattern.
Replace O-rings every 500,000 cycles or 2 years (whichever comes first).
Compatible with ISO VG 32 hydraulic fluids and standard air lubricants.
| Property | Property Value |
|---|---|
| sku | P-3V300M-R2 |
