Airtac PSB Single Acting Compact Cylinder PSB10X50CB
$20.43
Regular price
$27.93
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
PSB10X50CB
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Compliant with JIS standards
2. Miniature cylinder design featuring compact structure, reduced footprint, and lightweight construction
3. High-precision piston rod guidance with maintenance-free self-lubricating guide bearings
4. Front-end mounting only for PB4/PB6 models; Both front and rear-end mounting options available for PB10/PB12/PB16
5. Stainless steel piston rod and cylinder body ensure corrosion resistance in moderately aggressive environments
6. Multiple bore sizes and configurable mounting accessories for customized solutions
7. Optimized for high-frequency operations with rapid response characteristics through minimized bore dimensions
Category: Rod-type Cylinders | Brand: AIRTAC | Series: PSB
Installation guidelines:
Maximum side load ≤1.5N. For vertical mounting,
use speed controller (ASC-06) to prevent piston slam.
Lubricate every 500,000 cycles under continuous operation.
2. Miniature cylinder design featuring compact structure, reduced footprint, and lightweight construction
3. High-precision piston rod guidance with maintenance-free self-lubricating guide bearings
4. Front-end mounting only for PB4/PB6 models; Both front and rear-end mounting options available for PB10/PB12/PB16
5. Stainless steel piston rod and cylinder body ensure corrosion resistance in moderately aggressive environments
6. Multiple bore sizes and configurable mounting accessories for customized solutions
7. Optimized for high-frequency operations with rapid response characteristics through minimized bore dimensions
Category: Rod-type Cylinders | Brand: AIRTAC | Series: PSB
AirTAC PSB Single-Acting Compact Cylinder PSB10X50CB Specifications
- Model: PSB10X50CB
- Type: Single-acting spring return (piston type)
- Bore diameter: 10mm
- Stroke: 50mm
- Structure: Compact pen-type design
- Material: Aluminum alloy body (anodized finish)
- Installation types: Foot mounting, flange mounting options
- Operating pressure: 0.15–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Rubber buffer (both ends)
- Port size: M5x0.8 (Rc1/8 adapter optional)
- Weight: 0.22kg ±2%
- Dimensions: 100mm(L) × 28mm(W) × 28mm(H) (Full extension length: 150mm)
- Rod thread: M5x0.8 external thread
- Seal material: NBR rubber (standard), optional FKM
- Protection rating: IP40 (dust resistant)
Ultra-slim pneumatic cylinder optimized for space-constrained automation systems. Features a chrome-plated piston rod with integrated scraper for dust prevention. Spring return mechanism ensures fail-safe retraction. Requires 0.5-1.0μm filtered air with ISO VG32 lubricant (optional oil-free operation).
Typical Applications:
- Semiconductor wafer handling robots
- Food packaging machine clamp actuators
- Laboratory equipment positioning stages
- Pharmaceutical blister sealing machines
- Precision optical component alignment
- 3D printer filament feed mechanisms
Installation guidelines:
Maximum side load ≤1.5N. For vertical mounting,
use speed controller (ASC-06) to prevent piston slam.
Lubricate every 500,000 cycles under continuous operation.
Dynamic specs:
- Max theoretical force: 6.28N @0.6MPa
- Piston speed: 50-700mm/s (regulated)
- Spring force: 1.6N (return stroke)
- Ambient humidity: 35-85% RH (non-condensing)
| Property | Property Value |
|---|---|
| sku | PSB10X50CB |
| Rear Cover Type | Double Clevis Type |
| Mounting Type | Without Mounting Accessories |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-800mm/s |
| Port Size | M5×0.8 |
| Magnet | Non-magnetic |
| Bore Diameter | <10mm> |
| Stroke | <50mm> |
