Airtac PSB Single Acting Compact Cylinder PSB6X10R
The AirTAC Airtac PSB Single Acting Compact Cylinder PSB6X10R is a single acting, push type (spring return) pen-size mini cylinder with a Ø6mm bore and 10mm stroke. A single air port drives the push stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ6 mm
- Stroke10 mm
- Port sizeM5×0.8
- Acting typePush, single acting
- Rod threadM5×0.8
- ReturnSpring
About the Airtac PSB Single Acting Compact Cylinder PSB6X10R
The AirTAC PSB6X10R is a single-acting push cylinder with a built-in spring return, extending when air enters its single M5x0.8 port. It provides 10.6 N of net push at 0.5 MPa and 16.3 N at 0.7 MPa. This fail-safe design automatically retracts the rod upon air loss, keeping your equipment safe.
Built with a SUS304 stainless rod and barrel, the slim mini body fits tight jigs. A fixed TPU bumper cushions the stroke ends. Plan for a safe working load of roughly 6 N, which is about 60% of the 0.5 MPa rating, to account for seal friction.
Airtac PSB Single Acting Compact Cylinder PSB6X10R Technical Specifications
| Model | Airtac PSB Single Acting Compact Cylinder PSB6X10R |
|---|---|
| Series | PSB JIS pen-size mini cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 10 mm |
| Acting type | Single acting, push type (spring return) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are the usable push forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSB Single Acting Compact Cylinder PSB6X10R
| PSB | JIS pen-size single acting, push type (spring return) mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R / U / CB | Back cover: R axial inlet, U 90° side inlet, CB double clevis (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PTB (single-acting pull), PBD (double rod), PBR (front-mount).
Where the Airtac PSB Single Acting Compact Cylinder PSB6X10R Is Used
Small Part Ejection
Pushes lightweight plastic components out of machining centers. The spring return guarantees the ejector clears the workspace if air pressure drops.
Package Deflection Gate
Sorts small cartons on a conveyor line. Failsafe retraction pulls the gate back safely, preventing jams during an emergency stop.
Test Fixture Clamping
Secures delicate samples in laboratory equipment. The modest 6 N safe working load applies gentle pressure without crushing fragile materials.
Is the Airtac PSB Single Acting Compact Cylinder PSB6X10R the Right Cylinder?
This 6 mm bore generates 10.6 N net push at 0.5 MPa. If you need less force, the 4 mm bore offers 4.1 N; for more power, the 10 mm bore provides 29.8 N. The internal spring requires a minimum 0.2 MPa pressure to move the rod and holds it retracted without air.
The R suffix specifies an axial inline air inlet. Confirm your needs for bore, stroke, and mounting brackets, as this configuration omits the magnetic sensor switch. The slender Ø3 mm rod handles coaxial thrust well but requires an external guide for off-axis loads.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PSB Single Acting Compact Cylinder PSB6X10R FAQ
It delivers 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. Because an internal spring opposes the air stroke, a minimum pressure of 0.2 MPa is required before the rod extends.
It uses a fixed TPU bumper at each end to decelerate the stroke over the last few millimeters. It is not adjustable, so at high speeds with real tooling mass you should meter-out the exhaust or add an external shock absorber.
