Airtac PSB Single Acting Compact Cylinder PSB6X15R
The AirTAC Airtac PSB Single Acting Compact Cylinder PSB6X15R is a single acting, push type (spring return) pen-size mini cylinder with a Ø6mm bore and 15mm stroke. A single air port drives the push stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ6 mm
- Stroke15 mm
- Port sizeM5×0.8
- Acting typePush, single acting
- Rod threadM5×0.8
- ReturnSpring
About the Airtac PSB Single Acting Compact Cylinder PSB6X15R
The AirTAC PSB6X15R is a JIS pen-size single-acting push cylinder that extends via one M5x0.8 air port and retracts automatically via an internal spring. It yields 10.6 N of net push at 0.5 MPa and 16.3 N at 0.7 MPa, utilizing a slim SUS304 stainless body and a Ø3 mm rod with an M5x0.8 end thread. This fail-safe design ensures the rod pulls home whenever air pressure drops.
Because the return mechanism constantly opposes the air stroke, a minimum of 0.2 MPa is required before motion begins. The R suffix denotes an axial inlet for inline plumbing, simplifying tubing in dense layouts. A fixed TPU bumper cushions the stroke ends, and since no magnet is installed, positioning requires external mechanical stops.
Airtac PSB Single Acting Compact Cylinder PSB6X15R Technical Specifications
| Model | Airtac PSB Single Acting Compact Cylinder PSB6X15R |
|---|---|
| Series | PSB JIS pen-size mini cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 15 mm |
| Acting type | Single acting, push type (spring return) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are the usable push forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSB Single Acting Compact Cylinder PSB6X15R
| PSB | JIS pen-size single acting, push type (spring return) mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×15 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R / U / CB | Back cover: R axial inlet, U 90° side inlet, CB double clevis (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PTB (single-acting pull), PBD (double rod), PBR (front-mount).
Where the Airtac PSB Single Acting Compact Cylinder PSB6X15R Is Used
Small Part Ejector
Pushes lightweight stamped electronics from a die on an assembly line, relying on the spring to safely retract the pin when air is cut.
Package Diverter Gate
Acts as a compact routing flap actuator on a packaging conveyor, using the single air line to extend and block flow before springing back.
Lab Test Clamp
Secures delicate glass vials during a filling process with a soft 6 N working force, releasing instantly upon pneumatic exhaust.
Is the Airtac PSB Single Acting Compact Cylinder PSB6X15R the Right Cylinder?
Selecting this 6 mm bore over the smaller Ø4 grants higher thrust, while stepping up to a Ø10 bore provides 29.8 N at 0.5 MPa for heavier tooling. At 0.5 MPa, plan for a safe working load of roughly 6 N, which translates to lifting about 0.5 kg vertically with a sane 2:1 margin. The Ø3 mm rod is built for coaxial thrust, so add an external linear bearing if side loads are present.
Confirm your ordering essentials: 6 mm bore, 15 mm stroke, no magnet, R axial back cover, and standard mounting. Remember the internal spring sets the 0.2 MPa minimum operating pressure, and max pressure is 0.7 MPa.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PSB Single Acting Compact Cylinder PSB6X15R FAQ
The net usable push force is 10.6 N at 0.5 MPa and 16.3 N at 0.7 MPa. Because the internal spring opposes extension, a minimum operating pressure of 0.2 MPa is required to move the rod.
It uses a fixed TPU bumper at the stroke ends to decelerate motion over the last few millimeters. The spring automatically retracts the rod on air loss for a fail-safe home position, but it is not a locking brake for external loads.
