Airtac PSB Single Acting Compact Cylinder PSB6X50SR
The AirTAC Airtac PSB Single Acting Compact Cylinder PSB6X50SR is a single acting, push type (spring return) pen-size mini cylinder with a Ø6mm bore and 50mm stroke. A single air port drives the push stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ6 mm
- Stroke50 mm
- Port sizeM5×0.8
- Acting typePush, single acting
- Rod threadM5×0.8
- ReturnSpring
About the Airtac PSB Single Acting Compact Cylinder PSB6X50SR
The AirTAC PSB6X50SR is a JIS pen-size single-acting push cylinder with a 6 mm bore and 50 mm stroke. Air entering the single M5x0.8 port extends the Ø3 mm rod, while an internal spring ensures fail-safe retraction upon air loss, simplifying valving down to one solenoid line. It provides 10.6 N of net push at 0.5 MPa and 16.3 N at 0.7 MPa.
Built with a SUS304 stainless barrel and a slim mini body, this unit fits tight, damp jigs. The -S suffix denotes a built-in piston magnet for position sensing with reed or electronic switches. A fixed TPU bumper cushions the stroke ends, and because the return spring demands a minimum 0.2 MPa operating pressure, the rod stays securely retracted without live air.
Airtac PSB Single Acting Compact Cylinder PSB6X50SR Technical Specifications
| Model | Airtac PSB Single Acting Compact Cylinder PSB6X50SR |
|---|---|
| Series | PSB JIS pen-size mini cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 50 mm |
| Acting type | Single acting, push type (spring return) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are the usable push forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSB Single Acting Compact Cylinder PSB6X50SR
| PSB | JIS pen-size single acting, push type (spring return) mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R / U / CB | Back cover: R axial inlet, U 90° side inlet, CB double clevis (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PTB (single-acting pull), PBD (double rod), PBR (front-mount).
Where the Airtac PSB Single Acting Compact Cylinder PSB6X50SR Is Used
Small Part Ejection
Pushes lightweight stamped electronics parts out of a die on a packaging line, with the spring safely pulling the rod back when air is cut.
Sorting Diverter
Acts as a compact gate to deflect small plastic bottles on a conveyor, relying on the single air line to extend and block the flow path.
Lab Test Clamp
Secures delicate glass vials during a centrifuge spin cycle, applying just enough holding force without crushing the samples.
Is the Airtac PSB Single Acting Compact Cylinder PSB6X50SR the Right Cylinder?
This 6 mm bore yields 10.6 N net push at 0.5 MPa. If you need less force, the Ø4 version offers 4.1 N; if your load requires more, step up to the Ø10 bore at 29.8 N. Plan for a safe working load of about 6 N (roughly 60% of the 0.5 MPa figure) to account for seal friction, which translates to lifting about 0.5 kg vertically with a 2:1 safety margin.
At 50 mm of travel, the slender Ø3 mm rod needs an external guide or linear bearing to prevent side-loading damage. Confirm your ordering essentials: 6 mm bore, 50 mm stroke, S magnet, R axial inlet, and your preferred mounting bracket.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PSB Single Acting Compact Cylinder PSB6X50SR FAQ
The net usable push force is 10.6 N at 0.5 MPa and 16.3 N at 0.7 MPa (maximum pressure). Because an internal spring returns the rod, a minimum operating pressure of 0.2 MPa is required before the piston moves, and the rod fails safe to the retracted position on air loss.
It uses a fixed TPU bumper at each end to decelerate the last few millimeters of travel; at higher speeds with real tooling mass, meter-out the exhaust or add an external shock absorber. The S suffix indicates a built-in piston magnet compatible with AirTAC reed or electronic switches.
