Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R
The AirTAC Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R is a single acting, push type (spring return) pen-size mini cylinder with direct front-cover mounting (M3×0.5 thread). A single air port drives the push stroke on a Ø6mm bore, 50mm stroke; the return spring resets the rod when air is released.
- BoreØ6 mm
- Stroke50 mm
- Port sizeM5×0.8
- Front-mount threadM3×0.5
- Acting typePush, single acting
- ReturnSpring
About the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R
The AirTAC PSBR6X50R is a JIS pen-size single-acting push cylinder with a 50 mm stroke. Air entering the M5x0.8 port extends the rod, while an internal spring retracts it. This fail-safe design ensures the rod pulls home on air loss, needing only one solenoid line. It delivers 10.6 N of net push at 0.5 MPa.
A DIRECT front-cover M3x0.5 thread allows straight bolt-on mounting to your fixture, saving space. The SUS316L stainless barrel suits damp environments, and a fixed TPU bumper cushions the stroke ends. Plan for a safe working load of about 6 N (roughly 60% of the 0.5 MPa rating) to account for seal friction and smooth travel.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R Technical Specifications
| Model | Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R |
|---|---|
| Series | PSBR JIS pen-size front-mount cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm |
| Stroke | 50 mm |
| Acting type | Single acting, push type (spring return) |
| Front-mount thread | M3×0.5 |
| Port size | M5×0.8 |
|---|---|
| Operating pressure | 0.3 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (push by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod retracted; applying air pushes the rod out, and removing air lets the spring return it. Front cover carries the mounting thread (M3×0.5); barrel is SUS316L. Forces below are NET spring-deducted values. Confirm against the product label.
Net Push Force (Ø6mm)
| Pressure | Net push force |
|---|---|
| 0.5 MPa | 10.6 N |
| 0.7 MPa (max) | 16.3 N |
These are usable push forces after the return spring is subtracted, from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R
| PSBR | JIS pen-size front-mount single acting, push type (spring return) series. |
|---|---|
| 6 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| U / R | Back cover: U 90° side inlet or R axial inlet (bore-dependent). |
Mounting: direct front-cover thread (M3×0.5). Related PBR-family variants: PBR (double acting), PTBR (single-acting pull).
Where the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R Is Used
Small Part Ejection
Pushes lightweight plastic parts out of a machining nest. The fail-safe retract ensures the ejector clears the workspace if compressed air drops.
Panel Pusher
Acts as a compact pusher for thin electronic panels. The direct M3x0.5 front mount threads directly into tight assembly jigs without brackets.
Clamp Release
Releases a lightweight holding clamp via spring return. The single solenoid line simplifies wiring while providing a safe retracted state.
Is the Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R the Right Cylinder?
This 6 mm bore provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. If your task needs less force, stepping down is not an option as this is the smallest diameter. If you need more power, moving up to the 8 mm bore yields 18.7 N at 0.5 MPa. The internal spring sets a 0.3 MPa minimum pressure before motion begins.
The DIRECT front-cover M3x0.5 thread mounts straight to the jig without extra brackets. The R axial back cover provides in-line plumbing. The thin Ø3 mm piston rod handles coaxial thrust well, but over this 50 mm stroke you should add an external guide for any off-axis loads.
Quick checklist
- ✓ Net push force at your working pressure
- ✓ Bolt directly through the front cover (M3×0.5)
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe retract on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.3 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Match bolt size and engagement to the front thread.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
Airtac PSBR Single Acting Square Head Compact Cylinder PSBR6X50R FAQ
It provides 10.6 N net push at 0.5 MPa and 16.3 N at 0.7 MPa. The internal return spring requires a 0.3 MPa minimum pressure before the rod extends. It is single-acting push, so the spring holds the rod retracted on air loss.
It mounts directly via a front-cover M3x0.5 thread, separate from the M5x0.8 air port. The barrel is SUS316L stainless steel for damp environments. This specific model has no magnet for position sensing.
