Airtac PSS Exhaust Throttle Type Universal Speed Control Valve PSS1003A
AirTAC PSS1003A Exhaust Throttle Type Universal Speed Control Valve Specifications
- Model: PSS1003A
- Type: Exhaust throttle with multi-directional mounting
- Port size: 1/8" NPT (G1/8 optional)
- Operating pressure: 0.05–0.8 MPa
- Flow capacity: 0.12 Cv (at 6 bar)
- Adjustment method: Rotary knob with locking nut
- Adjustment range: 1/4 turn (min) to 5 turns (max)
- Body material: Brass with nickel plating
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 70℃
- Weight: ~82g
- Dimensions: 35mm(L) × 35mm(W) × 50mm(H)
- Mounting orientation: 360° rotatable
- Protection rating: IP40
- Vibration resistance: ≤10Hz with 1.5mm amplitude
Precision airflow regulator featuring dual-direction exhaust throttling for stable cylinder speed control. The universal mounting design allows 360° rotation adjustment for flexible installation in confined spaces. Integrated dust-resistant knob prevents debris ingress during adjustment.
- Pneumatic cylinder speed synchronization in assembly lines
- Packaging machine gripper positioning systems
- Medical bed actuator speed modulation
- Automated conveyor braking controls
- Textile machinery tension adjustment
Operation guidance:
For optimal performance, adjust flow rate under system pressure.
Always complete final tuning after 2-3 full actuator cycles.
Use with 5μm filter regulator upstream. Avoid overtightening -
maximum torque 0.3N·m during installation.
| Property | Property Value |
|---|---|
| sku | PSS1003A |
