Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB
The AirTAC Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB is a single acting, pull type (spring extend) pen-size mini cylinder with a Ø10mm bore and 5mm stroke. A single air port drives the pull stroke; the built-in return spring resets the rod when air is released, so only one solenoid line is needed.
- BoreØ10 mm
- Stroke5 mm
- Port sizeM5×0.8
- Acting typePull, single acting
- Rod threadM8×1.0
- ReturnSpring
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB
The AirTAC PTB10X5CB is a JIS pen-size single-acting pull cylinder where air entering one M5x0.8 port retracts the rod, and an internal spring pushes it back out. It delivers 23.5 N of net pull at 0.5 MPa (36.7 N at the 0.7 MPa maximum). Because the return spring constantly pushes outward, the rod automatically extends to a safe state if air pressure drops.
This variant uses a CB double clevis back cover for pivoting mountings and carries no sensor magnet. The slim SUS304 stainless body saves space on light end-of-arm tooling. A fixed TPU bumper cushions the stroke ends, and the M8x1.0 rod-end thread handles your tooling attachment.
Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB Technical Specifications
| Model | Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB |
|---|---|
| Series | PTB JIS pen-size mini cylinder |
| Bore size | Ø10 mm |
| Rod diameter | Ø4 mm |
| Stroke | 5 mm |
| Acting type | Single acting, pull type (spring extend) |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.2 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Return | Return spring (pull by air) |
| Max standard stroke | Up to 60 mm |
The spring holds the rod extended; applying air retracts it, and removing air lets the spring push the rod back out. Forces below are the NET spring-deducted values from the AirTAC thrust table. Confirm against the product label before installation.
Net Pull Force (Ø10mm)
| Pressure | Net pull force |
|---|---|
| 0.5 MPa | 23.5 N |
| 0.7 MPa (max) | 36.7 N |
These are the usable pull forces after the return spring is subtracted, taken directly from the AirTAC single-acting thrust table. Minimum operating pressure is set by the spring, so this model needs at least the lower pressure shown to move.
Model Code: Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB
| PTB | JIS pen-size single acting, pull type (spring extend) mini-cylinder series. |
|---|---|
| 10 | Bore size in mm. |
| ×5 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| R | Back cover: R axial inlet (bore-dependent). |
Mounting accessories: LB, FA, CJ. Related PB-family variants: PB (double acting), PSB (single-acting push), PBD (double rod), PBR (front-mount).
Where the Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB Is Used
Pivoting Hold-Down Clamp
Uses the CB double clevis to swing a small latch, pulling the rod back to unclamp a delicate part before the spring safely extends it.
Wire Belt Tensioner
Applies steady retraction to maintain tension on a light packaging belt, relying on the spring to slacken the line on air loss.
Retract-to-Open Gate
Pulls a miniature diverter gate out of the product stream upon actuation, letting the internal spring push the gate closed as a default.
Is the Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB the Right Cylinder?
When sizing this bore, note the 23.5 N net pull at 0.5 MPa is lower than the matching push cylinder because pull acts on the smaller rod-side area. If your pivoting clamp needs less force, stepping down to the Ø6 bore gives 7.1 N; if you need more retraction muscle, the Ø12 bore provides 33.1 N. The internal spring sets a 0.2 MPa minimum pressure before the rod moves, and the CB clevis requires a matching pin.
For real-world planning, target a safe working load of about 14 N (roughly 60 percent of the 0.5 MPa figure) to account for seal friction. Vertically, this translates to holding or pulling about 1.2 kg with a sane 2:1 margin. The Ø4 mm rod is built for coaxial thrust, so avoid side loads.
Quick checklist
- ✓ Net pull force at your working pressure
- ✓ Only one air line / solenoid needed
- ✓ Fail-safe extend on air loss
- ✓ Magnet (S) for sensors?
- ✓ Stroke ≤ 60 mm (single-acting limit)
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.2 – 0.7 MPa operating pressure.
- check Allow for spring force in the stroke direction.
- check Do not add an external return mechanism.
- check Keep the load coaxial; avoid side load on the thin rod.
- check Do not dismantle the front or back cover.
Airtac PTB Single Acting Pen-Type Cylinder PTB10X5CB FAQ
It provides 23.5 N of net pull at 0.5 MPa and 36.7 N at the 0.7 MPa maximum. The internal spring requires a minimum of 0.2 MPa before the rod moves, and the rod fails safe in the extended position without air.
It uses a fixed TPU bumper at each end to decelerate the last few millimeters of travel. Because it is not adjustable, you should meter-out the exhaust or add an external shock absorber when cycling real tooling mass at higher speeds.
