Airtac QCKR Rotary Clamping Cylinder QCKR12X10S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR12X10S Specifications
- Model: QCKR12X10S
- Type: Double-acting rotary clamping cylinder with auto-rotation mechanism
- Bore size: 12mm
- Stroke: 10mm (±0.5mm adjustment range)
- Rotation angle: 90° ±1° (clockwise/counter-clockwise selectable)
- Operating pressure: 0.1–0.8 MPa
- Maximum clamping force: 45N at 0.5MPa
- Piston speed: 50–700mm/s
- Buffer type: Rubber cushion (adjustable end dampers)
- Port thread: M5×0.8 (G1/8 adaptor available)
- Seal material: HNBR (Hydrogenated Nitrile) for high temperature resistance
- Ambient temperature: -20℃ to +80℃
- Weight: 0.25kg (without accessories)
- Dimensions: 100mm(L) × 45mm(W) × 45mm(H) (extended position)
- Mounting: Standard M4 threaded holes on 32mm × 32mm pattern
- Repeat positioning accuracy: ±0.1mm
- ISO certification: ISO 6432 compliant
Precision rotary clamping cylinder combining linear motion with 90° rotation for multi-axis positioning. Features anti-rotation guide pins and wear-resistant chrome-plated piston rod. Integrated T-slot allows direct mounting of custom jaws. Requires 5μm filtered dry air with ISO 8573-1:2010 Class 3.4.2 air quality.
- Robotic end-effector tool changers
- CNC machine fixture positioning
- PCB handling and testing equipment
- Automated assembly line pallet locking
- Medical device component alignment systems
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Use flexible tubing to accommodate rotation movement.
Max lateral load capacity: 15N at piston rod end.
| Property | Property Value |
|---|---|
| sku | QCKR12X10S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
