Airtac QCKR Rotary Clamping Cylinder QCKR12X10SFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR12X10SFB Technical Details
- Model: QCKR12X10SFB
- Type: Rotary clamp cylinder with mechanical lock
- Bore size: 12mm (0.47")
- Stroke: 10mm (0.39")
- Operating pressure: 0.1–0.9 MPa (14.5–130.5 PSI)
- Rotation angle: 90° ±5° (manual or pneumatic rotation options)
- Clamping force: 45N @ 0.5MPa
- Buffer type: Adjustable rubber cushion
- Mounting style: Compact flange mount (ISO 6432 standard)
- Port size: M5x0.8 (dual ports for air supply)
- Body material: Aluminum alloy (anodized finish)
- Piston rod: Stainless steel (SUS304)
- Seal material: NBR (nitrile) with wear-resistant ring
- Temperature range: -20℃ to 80℃ (-4℉ to 176℉)
- Weight: 0.25kg (0.55 lbs)
- Dimensions: 48mm(W) × 37mm(H) × 102mm(L) (1.89" × 1.46" × 4.02")
- Protection rating: IP40 (dust protected)
- Repeat accuracy: ±0.2mm
High-precision rotary clamping cylinder featuring a unique cam-lock mechanism for zero-backlash positioning. The dual-action design combines vertical stroke movement with 90° rotational locking, ideal for rapid tooling changes. Integrated wear sensors (optional) enable predictive maintenance monitoring.
- Robotic end-effector tool changers
- CNC machine fixture positioning
- PCB test probe locking mechanisms
- Medical device assembly stations
- Automotive welding jig systems
- Semiconductor wafer handling
Installation note:
Apply 0.5-1Nm torque during mounting to prevent housing deformation.
Use filtered air (5-40μm) with ISO VG32 lubricant. Perform rotational
alignment before pressure application. Maintenance cycle: Relubricate
every 500,000 cycles or 6 months.
| Property | Property Value |
|---|---|
| sku | QCKR12X10SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
