Airtac QCKR Rotary Clamping Cylinder QCKR12X10SMFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR12X10SMFB Technical Details
- Model: QCKR12X10SMFB
- Type: Rotary clamp cylinder with mechanical lock
- Bore size: Ø12mm
- Stroke: 10mm
- Rotation angle: 90° ±5°
- Clamping torque: 0.6 N·m (at 0.5 MPa)
- Operating pressure: 0.15–0.7 MPa
- Cushioning: Rubber buffer (non-adjustable)
- Body material: Aluminum alloy (anodized)
- Piston rod: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 70℃
- Port size: M5×0.8 (dual ports)
- Mounting type: Front flange with 4×M4 threaded holes
- Weight: 0.32 kg
- Dimensions: 90mm(L) × 42mm(W) × 42mm(H)
- Repeat accuracy: ±0.5mm
- IP rating: IP40 (dust protected)
Compact rotary clamping cylinder combining linear thrust and rotational motion, featuring integrated mechanical locking for zero-backlash positioning. Precision ground guide rods ensure smooth 90° rotation with 3μm surface finish. Includes anti-rotation safety pin for overload protection. Requires dry lubricated air (ISO 8573-1 class 3).
- CNC machine tool fixture switching
- Robotic arm end-effector tool changers
- PCB test probe positioning systems
- Medical device assembly stations
- Automotive component alignment jigs
- Optical lens polishing fixtures
Operation tip:
Apply 2-3 drops of ISO VG32 hydraulic oil monthly to rotating collar.
Avoid side load exceeding 15N during extension. For vertical mounting,
use counterbalance valve (not included). Maximum cycle rate: 120 cpm.
| Property | Property Value |
|---|---|
| sku | QCKR12X10SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
