Airtac QCKR Rotary Clamping Cylinder QCKR12X20S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR12X20S Technical Details
- Model: QCKR12X20S
- Type: Double-acting rotary clamp cylinder
- Bore size: 12mm
- Stroke: 20mm
- Operating pressure: 0.1-0.8 MPa
- Rotation angle: 90° ± 2°
- Clamping force: 80N @ 0.5MPa
- Piston speed: 50-500mm/s
- Port size: M5x0.8 (G1/8 adaptor available)
- Body material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal type: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.48kg ±2%
- Dimensions: 124mm(L) × 42mm(W) × 42mm(H)
- Mounting: Standard M6 threaded holes (4 places)
- Protection class: IP54 (standard sealing)
Compact rotary clamping cylinder combining 90° rotation with vertical clamping motion. Features dual anti-rotation guides for precise positioning accuracy (±0.5mm repeatability). Integrated wear-resistant bushings ensure 500km minimum service life. Requires ISO 8573-1:2010 Class 3 compressed air.
- CNC machine tool fixture positioning
- Robotic arm end-effector tool changing
- PCB assembly line component retention
- Automated inspection station workpiece alignment
- Packaging machine rotary indexing systems
Operation guidance:
Sequence control required - complete rotation before clamping.
Lubricate pivot points every 500,000 cycles using ISO VG32 hydraulic oil.
Avoid side load exceeding 15N during operation.
| Property | Property Value |
|---|---|
| sku | QCKR12X20S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
