Airtac QCKR Rotary Clamping Cylinder QCKR12X20SFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR12X20SFB Technical Details
- Model: QCKR12X20SFB
- Bore size: Ø12mm
- Stroke: 20mm
- Operation type: Double-acting with rotary clamp mechanism
- Working pressure: 0.1-0.9 MPa
- Temperature range: -10℃ to 70℃
- Cushioning: Adjustable rubber buffer
- Mounting style: Standard flange base (FB type)
- Port size: M5x0.8 (dual ports)
- Material: Aluminum alloy body, CRCCA piston rod
- Protection class: IP54
- Rotation angle: 90°±5° (clockwise/counter-clockwise)
- Clamping force: 32N @ 0.5MPa
- Weight: 0.45kg ±3%
- Dimensions: Ø34mm × 117.5mm (L) [including mounting flange]
Compact rotary clamping cylinder combining linear motion with 90° rotation, featuring precision-ground piston rod and wear-resistant seals. The dual-chamber design enables simultaneous clamping and positioning operations. Integrated T-slot on flange allows direct workpiece mounting. Requires filtered lubricated air (ISO 8573-1 class 3.4.2).
- Robotic end-effector tool changing systems
- CNC machine fixture positioning
- PCB assembly line component retention
- Modular production test station clamping
- Medical device manufacturing jigs
Operation tip:
Always engage rotation before applying full clamping pressure.
Use speed controller (ASC-06) on exhaust ports to prevent sudden
rotation impact. Maximum recommended cycle rate: 120 cpm.
| Property | Property Value |
|---|---|
| sku | QCKR12X20SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 12mm |
| Direction Code | Right-hand |
