Airtac QCKR Rotary Clamping Cylinder QCKR16X10S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X10S Specifications
- Model: QCKR16X10S
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 10mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90° ±5° (standard)
- Clamping torque: 0.8 N·m @ 0.5 MPa
- Port size: M5 × 0.8 (Rc1/8 adapter optional)
- Cushioning: Adjustable rubber buffer
- Seal material: NBR/PU hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 0.68 kg (excluding accessories)
- Dimensions: 100mm(L) × 48mm(W) × 48mm(H) (clamping arm extended)
- Mounting pattern: 32mm × 32mm (ISO 21287 compatible)
- Material: Anodized aluminum body with hardened steel guide
- Repeat accuracy: ±0.5°
- Lubrication: Pre-lubricated (Grease-free operation)
High-precision rotary clamp cylinder combining linear thrust and angular rotation in one compact unit. Features zero-backlash gear mechanism with double piston design for stable clamping force. Integrated T-slot mounting groove allows flexible installation. Requires filtered air (25μm+) with 1-10 cSt viscosity oil mist if lubricated.
- CNC machine tool workpiece fixturing
- Robotic welding jig positioning
- Automated inspection equipment clamping
- Electronics assembly press-fit operations
- Medical device manufacturing tooling
Installation note:
Align clamping arm within ±0.2mm tolerance during setup. Use locking compound
on mounting screws (M5 × 0.8, torque 2.0 N·m max). Maintain 0.3-0.5mm clearance
between clamp nose and workpiece surface.
| Property | Property Value |
|---|---|
| sku | QCKR16X10S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
