Airtac QCKR Rotary Clamping Cylinder QCKR16X10SFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR16X10SFB Rotary Clamping Cylinder Specifications
- Model: QCKR16X10SFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 10mm
- Rotation angle: 90° ±5° (configurable)
- Operating pressure: 0.1–0.8 MPa
- Operating temperature: -20℃ to 80℃
- Port size: M5x0.8 (dual ports)
- Piston material: Aluminum alloy with hard anodizing
- Seal material: NBR (Nitrile rubber)
- Mounting type: Standard flange with 4xM4 threaded holes
- Weight: 0.48kg ±2%
- Dimensions: 80mm(L) × 32mm(W) × 32mm(H)
- Rotational torque: 0.25 N·m at 0.5 MPa
- Repeat accuracy: ±0.2mm
- Protection rating: IP54
Precision rotary clamping cylinder with integrated mechanical locking mechanism, featuring dual pneumatic ports for bidirectional control. The hardened piston rod and wear-resistant seals enable >2 million cycles at rated pressure. Optimized for high-speed clamping with anti-vibration design in rotating components.
- CNC machine tool fixture positioning
- Robotic arm end-effector tool changing
- PCB assembly line component retention
- Automated inspection equipment workholding
- Packaging machine rotary indexing stations
Operation note:
Requires clean compressed air (ISO 8573-1:2010 class 4.4.3) with 1-3 drops of ISO VG32 turbine oil per m³.
Avoid lateral loads exceeding 15N during rotation. Lubricate guide shafts every 500 operating hours.
| Property | Property Value |
|---|---|
| sku | QCKR16X10SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
