Airtac QCKR Rotary Clamping Cylinder QCKR16X10SMFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X10SMFB Specifications
- Model: QCKR16X10SMFB
- Type: Rotary clamping cylinder with mechanical lock
- Bore diameter: 16mm
- Stroke: 10mm
- Rotation angle: 90° (±5° adjustable)
- Operating pressure: 0.1–0.7 MPa
- Operating temperature: -10℃ to 60℃ (with NBR seals)
- Port size: M5x0.8 (standard), G1/8 optional
- Rotation torque: 0.25 N·m (at 0.5 MPa)
- Clamping force: 63N (at 0.5 MPa)
- Buffer type: Adjustable pneumatic cushioning
- Mounting style: Standard base mount with 4x M4 threaded holes
- Material: Aluminum alloy body, hardened steel guide rod
- Seal material: NBR (nitrile rubber)
- Repeat positioning accuracy: ±0.1mm
- Weight: 0.65kg (including accessories)
- Dimensions: 82mm(L) × 34mm(W) × 34mm(H) (excluding rod extension)
- Allowable lateral load: 15N max
- ISO standard: 6432 compliant
High-precision rotary clamping cylinder featuring a dual-action mechanism combining linear motion with 90° rotation. The integrated mechanical lock ensures zero drift during clamping operations. Anodized surface treatment provides corrosion resistance in humid environments. Includes built-in magnetic sensor slots (inductive sensor not included).
- CNC machine tool fixture positioning
- Automated welding jig systems
- PCB handling robots end-effectors
- Pharmaceutical blister packaging machines
- Semiconductor wafer handling systems
Operation guidance:
Maintain air filtration at 5-40μm with ISO 8573-1:2010 Class 4 standards.
Lubricate through air supply (ISO VG32 turbine oil recommended) at 1 drop/m³.
Avoid side impacts exceeding 10N during rotation phase.
| Property | Property Value |
|---|---|
| sku | QCKR16X10SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
