Airtac QCKR Rotary Clamping Cylinder QCKR16X20SM
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X20SM Technical Specifications
- Full Model Code: QCKR16X20SM
- Type: Double-acting rotary clamping cylinder
- Bore size: Ø16 mm
- Stroke: 20 mm (±1mm tolerance)
- Rotation angle: 90° ±2° (clockwise/counter-clockwise selectable)
- Operating pressure: 0.2-0.9 MPa
- Clamping force: 136N @0.5MPa (calculated with 85% efficiency factor)
- Port size: M5×0.8 (standard) with optional G1/8 adaptor
- Piston speed: 50-700 mm/s (lubricated condition)
- Cushioning: Adjustable rubber bumper (both ends)
- Seal material: NBR + polyurethane composite
- Ambient temperature: -20℃ to +80℃
- Protection rating: IP40 (IP67 available with optional wiper)
- Mounting type: Dual M5 threaded holes (base) + through-hole clamp slot
- Weight: 0.42 kg (bare cylinder), 0.58 kg (with standard accessories)
- Dimensions:
- Total length: 102 mm (extended)
- Body diameter: Ø32 mm
- Mounting base: 45mm(W) × 25mm(D)
- Rod end thread: M6×1.0
This precision rotary clamping cylinder combines 20mm linear stroke with 90° rotational movement in a compact package. The dual-chamber design enables simultaneous rotation and clamping actions through separate air circuits. Features chrome-plated piston rod and anodized aluminum body for corrosion resistance. Requires ISO 8573-1:2010 Class 3 compressed air.
- Air pressure enters rotation chamber (Port R) to initiate 90° turn
- Clamping action engages via Port A/B after rotation completes
- Built-in mechanical lock maintains position during power loss
- CNC machine tool fixture positioning
- PCB handling robotic end effectors
- Automated inspection station part orientation
- Pharmaceutical blister packaging rotation-sealing
Installation requirements:1. Use mounting bracket PN: QCKR-MB16 with 4.8Nm torque
2. Lubricate with ISO VG32 hydraulic oil during assembly
3. Maintain 0.3mm minimum clearance between clamp jaw and workpiece
4. Cycle rate ≤15 CPM for optimal service life
| Property | Property Value |
|---|---|
| sku | QCKR16X20SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
