Airtac QCKR Rotary Clamping Cylinder QCKR16X30S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X30S Technical Details
- Model: QCKR16X30S
- Bore size: 16mm
- Stroke: 30mm
- Rotation angle: 180° ±5° (adjustable)
- Operating pressure: 0.1-0.9 MPa
- Port size: M5×0.8 (standard) / NPT1/8 (optional)
- Piston material: Aluminum alloy with hard anodization
- Rod material: Stainless steel SUS304
- Seal type: NBR wear-resistant seals
- Temperature range: -20℃ to 80℃
- Clamping force: 98N @0.5MPa
- Weight: 0.58kg ±2%
- Dimensions: 107mm(L) × 50mm(W) × 50mm(H)
- Mounting pattern: 32mm × 32mm square flange
- Repeat positioning accuracy: ±0.5mm
- Air consumption: 12.1cm³ per cycle
Compact rotary clamping cylinder combining 180° rotation with vertical clamping motion. Features dual-stage sealing for leak prevention and anti-rotation guide pins for precise angular positioning. The nickel-plated end caps provide corrosion resistance in humid environments. Requires ISO 8573-1:2010 Class 3 compressed air.
- CNC machine tool fixture positioning
- Automated welding jig rotation systems
- PCB board clamping in SMT assembly lines
- Pharmaceutical blister packaging rotation units
- Robotic end-effector tool changers
Operation guidance:
Lubricate with ISO VG32 hydraulic oil monthly. Avoid side-load forces exceeding 15N
during clamping. For vertical mounting, install locking collar (sold separately)
to prevent gravity-induced rotation drift.
| Property | Property Value |
|---|---|
| sku | QCKR16X30S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
