Airtac QCKR Rotary Clamping Cylinder QCKR16X30SMFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR16X30SMFB Specifications
- Model: QCKR16X30SMFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 16mm
- Stroke: 30mm
- Operating pressure: 0.1–0.8 MPa
- Rotation mechanism: Rack-and-pinion driven
- Rotation angle: 180° (±1° precision)
- Port size: PT1/8 (G1/8 optional)
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP40
- Weight: 0.53kg ±2%
- Dimensions: 130mm(L) × 50mm(W) × 50mm(H)
- Rod end thread: M6×1.0 internal thread
- Mounting type: Through-hole base mount (SMFB series)
Compact rotary clamping cylinder combining linear thrust and rotational torque for precision workpiece positioning. Features hardened stainless steel guide rod (HRC45-50) and self-lubricating bronze bushings. The SMFB base version allows direct mounting through M5 screws with anti-vibration washers. Includes built-in magnetic sensor slot (NPN/PNP compatible) for position feedback.
- CNC machine tool fixture switching
- Automotive part transfer systems
- Electronics PCB clamping stations
- Robotic welding positioners
- Medical device assembly jigs
Installation note:
Requires 0.5Nm torque for base screws. Lubricate pinion teeth with ISO VG32 hydraulic oil
during maintenance. Avoid side-load exceeding 15N during rotation phase. Cycle rate should
not exceed 80% duty cycle at maximum pressure.
| Property | Property Value |
|---|---|
| sku | QCKR16X30SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | 16mm |
| Direction Code | Right-hand |
