Airtac QCKR Rotary Clamping Cylinder QCKR20X10S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR20X10S Rotary Clamping Cylinder Specifications
- Model: QCKR20X10S
- Type: Double-acting rotary clamping cylinder
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.1–0.7 MPa
- Operation method: Pneumatic rotary + linear motion
- Rotation angle: 90° (±5° adjustable)
- Port size: PT1/8 (G1/8 optional)
- Cushioning: Adjustable rubber buffer
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Protection rating: IP40
- Weight: 0.6kg (excluding accessories)
- Dimensions: 120mm(L) × 40mm(W) × 40mm(H)
- Clamping force: 127N @0.5MPa
- Rotation torque: 0.8N·m @0.5MPa
- Repeat accuracy: ±0.5mm
Compact rotary clamping cylinder combining linear thrust and 90° rotation for precision workpiece positioning. Features dual piston guides for enhanced stability and anti-rotation pins preventing unintended movement. The anodized aluminum body ensures corrosion resistance in humid environments.
- CNC machine tool fixture clamping
- Automated assembly line positioning
- Robotic arm end-effector tooling
- Precision measurement equipment locking
- PCB handling and alignment systems
- Packaging machine component indexing
Installation note:
Ensure proper alignment of rotary axis before operation. Lubricate with ISO VG32 hydraulic oil
for initial use. Maximum lateral load capacity: 30N. Allow 0.5mm clearance around rotating parts.
Critical parameters:
Do not exceed 1,200 cycles/hour for continuous operation. Use M5x0.8 mounting screws
with 4.4N·m torque specification. Requires 5μm filtered air supply.
| Property | Property Value |
|---|---|
| sku | QCKR20X10S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
