Airtac QCKR Rotary Clamping Cylinder QCKR20X10SFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR20X10SFB Rotary Clamping Cylinder Specifications
- Model: QCKR20X10SFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 20mm
- Stroke: 10mm
- Rotation angle: 90° ±5°
- Operating pressure: 0.1–0.8 MPa
- Operation method: Dual piston rack-and-pinion rotation mechanism
- Cushioning: Built-in adjustable rubber buffer
- Mounting style: Side flange (standard)
- Port size: M5×0.8 (1/8 PT optional)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 0.48 kg (without accessories)
- Dimensions:
- Length (retracted): 77mm
- Width (body): 32mm
- Height (flange base): 56mm
- Mounting hole spacing: 25mm × 25mm
Precision rotary clamping cylinder featuring synchronized linear motion and 90° rotation through hardened steel rack-and-pinion gearing. The dual-piston design ensures balanced torque output (max 1.96N·m @0.6MPa) with integrated anti-rotation guides. Chrome-plated piston rod with wear-resistant scraper seal. Includes magnetic piston for position sensing compatibility.
- Automated fixture positioning in CNC machining centers
- Workpiece orientation in robotic assembly lines
- Clamping/unclamping operations in semiconductor test handlers
- Rotary locking mechanisms in packaging machinery
- Precision alignment in optical component manufacturing
Installation guidelines:
Maintain concentricity within 0.2mm during mounting. Lubricate with ISO VG32 hydraulic oil before initial use.
For vertical installations, use auxiliary support brackets when cycle rate exceeds 50 CPM. Avoid side-load forces >15N.
| Property | Property Value |
|---|---|
| sku | QCKR20X10SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
