Airtac QCKR Rotary Clamping Cylinder QCKR20X10SM
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR20X10SM Specifications
- Model: QCKR20X10SM
- Type: Single-piston rod double-acting with rotary clamping
- Bore size: 20mm
- Stroke: 10mm
- Operating pressure: 0.1–0.8 MPa
- Structure: Compact rotary-lock mechanism with integrated guide
- Mounting: Standard base mounting (ISO 15552 compatible)
- Material:
- Cylinder tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR (standard), optional FKM available
- Port size: 2×M5 (G1/8 adaptor included)
- Cushioning: Adjustable pneumatic cushion at both ends
- Temperature range: -20℃ to 80℃
- Protection rating: IP40 (IP67 with optional bellows)
- Weight: 0.85kg ±2%
- Dimensions:
- Length (retracted): 130mm
- Width (body): 40mm
- Height (with mounting base): 55mm
- Rotation angle: 90° ±2°
- Clamping force: 150N @ 0.6MPa
- Repeat positioning accuracy: ±0.2mm
High-precision rotary clamping cylinder featuring a unique cam-lock mechanism that combines linear motion with 90° rotation. The hardened guide rail ensures smooth rotation under lateral loads. Includes wear-resistant bronze bushings and dual dust wipers for extended service life. Requires filtered air (5-50μm) with ISO VG32 lubricant (optional oil-free operation).
- CNC machine tool fixture positioning
- Automated welding jig clamping systems
- PCB handling robotic end-effectors
- Pharmaceutical blister packaging sealing
- Automotive part inspection station locking
Installation note:
Maintain 0.5-1mm clearance between clamp arm and workpiece.
Lubricate guide rail monthly with silicone-free grease (MLG-2 recommended).
Avoid side impact forces exceeding 30N during operation.
| Property | Property Value |
|---|---|
| sku | QCKR20X10SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <10mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
