Airtac QCKR Rotary Clamping Cylinder QCKR20X20S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR20X20S Technical Details
- Model: QCKR20X20S
- Bore diameter: 20mm
- Stroke: 20mm
- Rotation angle: 90°±5° (clockwise/counter-clockwise)
- Operating pressure: 0.1–0.8 MPa
- Holding torque: 2.5 N·m (at 0.5 MPa)
- Port size: M5x0.8 (dual Rc1/8 optional)
- Body material: Aluminum alloy (anodized finish)
- Piston rod: Stainless steel SUS304
- Seal material: NBR + Polyurethane
- Temperature range: -20℃ to +80℃
- Weight: 0.68 kg ±3%
- Dimensions: 80mm(L) × 52mm(W) × 55mm(H) (excluding mounting accessories)
- Protection class: IP54 (standard dust/moisture resistance)
- Air cushion: Adjustable buffer at both ends
- Mounting options: Standard base plate with 4×M5 threaded holes
Compact rotary-clamp integrated cylinder combining linear motion with 90° rotation, featuring a dual-action self-locking mechanism for secure workpiece fixation. The precision-ground guide rails ensure ≤0.15mm repeat positioning accuracy. Requires 5μm filtered lubricated air (ISO 8573-1 class 3).
- CNC machine tool automatic chuck systems
- Robotic welding fixture positioning
- Electronics assembly conveyor locking stations
- Automotive part inspection jigs
- Pharmaceutical packaging mold clamping
Installation guidelines:
Maintain ≤0.2mm parallelism between cylinder base and mounting surface.
Use M5x0.8 counterbore screws (recommended torque 2.0 N·m).
Allow 15mm clearance for rotary arm movement. Lubricate via inlet port every 500km operation.
| Property | Property Value |
|---|---|
| sku | QCKR20X20S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
