Airtac QCKR Rotary Clamping Cylinder QCKR20X20SFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR20X20SFB Rotary Clamping Cylinder Technical Details
- Model: QCKR20X20SFB
- Type: Double-acting rotary clamp cylinder with auto-rotation mechanism
- Bore size: 20mm
- Stroke: 20mm
- Operating pressure: 0.1–0.8 MPa (14.5–116 psi)
- Temperature range: -10℃ to 70℃ (14°F to 158°F)
- Cushion type: Adjustable rubber buffer
- Mounting style: Front flange with 4×M5 threaded holes
- Port size: M5×0.8 (G1/8 adaptor included)
- Material:
- Cylinder body: Aluminum alloy (hard anodized)
- Piston rod: Stainless steel SUS304
- Seals: NBR (nitrile rubber)
- Rotation angle: 90°±2°
- Clamping torque: 0.6 Nm at 0.5 MPa
- Repeat positioning accuracy: ±0.5°
- Protection rating: IP40
- Weight: 0.65 kg (1.43 lbs)
- Dimensions: 150mm(L) × 40mm(W) × 40mm(H)
Precision rotary clamping cylinder combining linear thrust and angular positioning in one compact unit. Features integrated T-slot for tooling plate attachment and magnetic sensor groove (sensor not included). The self-locking mechanism maintains position during power loss, with anti-rotation pins ensuring mechanical stability. Requires clean, dry air with 25-μm filtration.
- Robotic arm end-effector tool changing
- CNC machine fixture positioning
- PCB assembly press-fit operations
- Automated inspection station workpiece locking
- Medical device manufacturing jigs
Installation note:
Maintain 0.5-1mm clearance between clamping surface and workpiece.
Lubricate with ISO VG32 hydraulic oil mist lubrication.
Max lateral load: 30N at piston rod extension.
| Property | Property Value |
|---|---|
| sku | QCKR20X20SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
