Airtac QCKR Rotary Clamping Cylinder QCKR20X20SMFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR20X20SMFB Rotary Clamping Cylinder Specifications
- Model: QCKR20X20SMFB
- Type: Double-acting rotary clamping cylinder
- Bore size: 20mm
- Stroke: 20mm (±5° rotation)
- Operating pressure: 0.1–0.9 MPa
- Torque output: 1.6–14.5 N·m (pressure-dependent)
- Rotation angle: 90° (±5° adjustable)
- Port size: M5×0.8 (dual ports)
- Piston material: Aluminum alloy (hard anodized)
- Rod material: Stainless steel SUS304
- Seal material: NBR (nitrile rubber)
- Temperature range: -10℃ to 80℃
- Weight: 1.8 kg (with standard accessories)
- Dimensions: 130mm(L) × 42mm(W) × 47mm(H)
- Mounting hole spacing: 30mm × 30mm (M5 threaded)
- Repeat positioning accuracy: ±0.2mm
- Response time: ≤0.3s (at 0.5 MPa)
Precision rotary clamping cylinder with integrated cam mechanism for simultaneous linear motion and 90° rotation. Features wear-resistant chromium-plated guide rods and anti-vibration end caps. Includes adjustable mechanical stoppers for rotation angle fine-tuning. Requires ISO 8573-1:2010 Class 3 compressed air.
- CNC machine tool workpiece positioning
- Robotic arm end-effector tool changing
- Automated assembly line fixture systems
- Semiconductor wafer handling equipment
- Precision mold clamping mechanisms
Installation note:
Apply ISO VG32 hydraulic oil to guide rails monthly.
Maintain 0.1–0.3mm clearance between clamp arm and workpiece surface.
Use shock absorbers for cycle rates exceeding 30 CPM.
Critical parameters:
Maximum side load 150N, axial load 800N.
Do not exceed 120% of rated pressure during commissioning.
Lubricator required if air oil mist <3μm not available.
| Property | Property Value |
|---|---|
| sku | QCKR20X20SMFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | <20mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
