Airtac QCKR Rotary Clamping Cylinder QCKR20X30S
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR20X30S Specifications
- Model: QCKR20X30S
- Type: Double-piston rod rotary clamping cylinder
- Bore size: 20 mm
- Stroke: 30 mm
- Operating pressure: 0.1-0.8 MPa
- Clamping force: 160 N @ 0.5 MPa
- Rotation angle: 90° ±5°
- Mounting style: Standard flange mounting
- Cushioning: Built-in air cushion (adjustable)
- Material: Aluminum alloy body, NBR seals
- Temperature range: -20℃ to +80℃
- Weight: 0.82 kg
- Dimensions (L×W×H): 180mm × 64mm × 64mm
- Port size: M5×0.8 (dual ports)
- Repeat positioning accuracy: ±0.5°
- Maximum rotation speed: 150 rpm
- Protection rating: IP54 (standard)
The QCKR series features a unique dual-piston rotary mechanism that combines 90° rotation with vertical clamping in one compact unit. The QCKR20X30S model delivers 160N clamping force with smooth rotation transition, using precision-ground helical gears and hardened guide rails for extended service life. Its anti-vibration design maintains position stability under dynamic loads.
- CNC machine tool fixture switching systems
- Automated robotic welding positioners
- Electronics assembly precision alignment
- Medical device manufacturing clamping stations
- Packaging line rotary indexing mechanisms
Installation tips:
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3-0.6 MPa operating pressure for optimal torque output.
Avoid side load exceeding 20N during rotation phase.
Allow 15°C minimum warm-up time in sub-zero environments.
| Property | Property Value |
|---|---|
| sku | QCKR20X30S |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
