Airtac QCKR Rotary Clamping Cylinder QCKR20X30SFB
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR20X30SFB Specifications
- Model: QCKR20X30SFB
- Type: Double-acting rotary clamp cylinder
- Bore size: 20mm
- Stroke: 30mm
- Operating pressure: 0.1–0.9 MPa
- Rotation angle: 90° ± 2°
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Buffer type: Adjustable rubber cushion
- Seal material: NBR (Nitrile rubber)
- Temperature range: -10℃ to 80℃
- Mounting style: Standard flange mounting
- Weight: 1.2kg ±5%
- Dimensions: 138mm(L) × 40mm(W) × 40mm(H)
- Rod thread: M10×1.25
- Repeat positioning accuracy: ±0.2mm
- Max lateral load: 15N
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision rotary clamping cylinder combining linear motion with 90° rotation, featuring hardened stainless steel guide rod and anodized aluminum body. The dual-piston design ensures smooth rotation and precise positioning, with integrated shock absorption for high-cycle applications (up to 1,500,000 cycles). Includes anti-rotation keyway and dust-resistant seals.
- Automated fixture positioning in CNC machining centers
- Workpiece clamping in robotic welding systems
- Pallet locking in assembly line transfer units
- Tool changing mechanisms in precision equipment
- Orientation adjustment in packaging machinery
Installation note:
Maintain parallel alignment between cylinder axis and load direction.
Use locking compound on mounting screws (Torque ≤3.5N·m).
Requires 5μm filtered air with 1-10 cSt viscosity oil mist lubrication for optimal performance.
- Max rotation speed: 60 RPM
- Allowable moment: 0.8N·m (static), 0.3N·m (dynamic)
- Breakaway pressure: ≥0.15MPa
- Air consumption: 27.5cm³/stroke (at 0.5MPa)
| Property | Property Value |
|---|---|
| sku | QCKR20X30SFB |
| Mounting Type | Rear Cover Flange Connecting Plate |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
