Airtac QCKR Rotary Clamping Cylinder QCKR20X30SM
2. Features a stainless steel wiper ring integrated into the front cover for robust protection against welding slag and industrial debris, offering superior reliability over conventional dust boots;
3. Maintains identical mounting dimensions and compatibility with ACQ series, allowing shared use of ACQ mounting accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QCKR
AirTAC QCKR Rotary Clamping Cylinder QCKR20X30SM Technical Details
- Model: QCKR20X30SM
- Type: Double-acting rotary clamping cylinder
- Bore size: 20mm
- Stroke: 30mm
- Rotation angle: 90° ±2°
- Operating pressure: 0.1-0.9 MPa
- Clamping force: 118N @0.5MPa
- Torque output: 0.8N·m @0.5MPa
- Port size: M5×0.8 (standard) / NPT1/8 optional
- Cushioning: Adjustable rubber buffer
- Body material: Aluminum alloy (anodized)
- Piston rod: Chrome-plated steel
- Seal type: NBR seals (oil-resistant)
- Ambient temperature: -20℃ to 80℃
- Repeat positioning accuracy: ±0.5°
- Weight: 0.68kg ±3%
- Dimensions:
- Extended length: 131mm
- Retracted length: 101mm
- Body width: 42mm
- Mounting base height: 20mm
- Rotation shaft diameter: 12mm
- ISO certification: 6431/VDMA 24562 standards
High-precision rotary clamping cylinder combining linear thrust with angular positioning, featuring integrated T-slot mounting grooves for flexible tooling attachment. The anti-rotation guide mechanism ensures stable angular alignment during clamping operations. Requires filtered air (5-50μm) with optional lubricator (ISO VG32 recommended).
- CNC machine tool fixture positioning
- Automotive welding jig locking systems
- PCB assembly line component retention
- Robotic end-effector tool changing stations
- Medical device assembly precision clamping
Operation note:
Always engage manual release lever before mechanical adjustments.
Maximum permissible side load: 15N. Lubrication interval: 2,000km stroke
travel or 6 months (whichever comes first).
| Property | Property Value |
|---|---|
| sku | QCKR20X30SM |
| Mounting Type | Without Mounting Accessories |
| Clamping Stroke | 30mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 50-200 mm/s |
| Port Size | M5×0.8 |
| Magnet | S-Magnetic |
| Bore Diameter | <20mm> |
| Direction Code | Right-hand |
