Airtac QDKR Pivoting Clamping Cylinder QDKR40X5SU
1. Achieves rotational motion at identical elevation level with zero rotational stroke, offering enhanced spatial efficiency compared to QCK series in confined environments;
2. Versatile mounting configurations with optional front cover boss-type or flat-type designs;
3. Dual-pin rotational guide groove mechanism ensures smooth operation and exceptional repeat positioning accuracy (±0.5°);
4. Integrated sensor mounting grooves on cylinder periphery enable direct installation without auxiliary accessories.
Category: Rotary Clamping Cylinders | Brand: AirTAC | Series: QDKR
AirTAC QDKR40X5SU Rotary Clamping Cylinder Specifications
- Model: QDKR40X5SU
- Type: Double-acting rotary clamp cylinder with integrated guide
- Bore size: 40mm
- Stroke: 5mm
- Operating pressure: 0.1–0.8 MPa (14.5–116 PSI)
- Rotation angle: 180° ±5°
- Actuation: Pneumatic (air supply required)
- Cushioning: Adjustable rubber buffer
- Mounting style: Side flange mounting (ISO 15552 standard)
- Port size: G1/8 (Rc1/8 optional)
- Temperature range: -20℃ to 80℃
- Material:
- Cylinder tube: Aluminum alloy with hard anodizing
- Piston rod: Stainless steel (SUS304)
- Seals: NBR (Nitrile rubber)
- Protection class: IP40
- Weight: 1.8kg (3.97 lbs)
- Dimensions:
- Length (retracted): 147mm
- Width (flange to flange): 82mm
- Height (including mounting base): 105mm
Precision rotary clamping cylinder combining linear motion with 180° rotation, featuring dual-position locking mechanism for secure workpiece fixation. The hardened guide rails ensure ≤0.05mm repeat positioning accuracy. Requires filtered lubricated air (ISO 8573-1:2010 Class 3.4.2) with 20-30μm filtration.
- CNC machining center tooling plate clamping
- Automated welding fixture positioning
- PCB assembly line component retention
- Automotive part transfer systems
- Medical device manufacturing jigs
Installation guidelines:1. Align cylinder axis within 0.2° of perpendicular to work surface
2. Maintain 0.5-1mm clearance between clamp arm and workpiece
3. Use anti-vibration washers on mounting bolts
4. Lubricate sliding surfaces with ISO VG32 hydraulic oil monthly
Avoid lateral forces exceeding 120N during operation.Maximum permissible moment: 18N·m (axial), 12N·m (radial)
| Property | Property Value |
|---|---|
| sku | QDKR40X5SU |
| Front Cover Type | Flat Type |
| Clamping Stroke | <5mm> |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20 to 70°C Rotation Angle: 90° |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Direction Code | Right-hand |
