Airtac RMSF Magnetic Coupling Rodless Cylinder RMSF20X750
$197.03
Regular price
$204.53
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
RMSF20X750
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1、Magnetically coupled rodless cylinder design eliminates mechanical linkage between piston and slider, ensuring superior sealing performance;
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
Operation guidelines:
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
AirTAC RMSF Magnetic Coupled Rodless Cylinder RMSF20X750 Technical Details
- Model: RMSF20X750
- Bore size: Ø20mm
- Stroke: 750mm
- Operating pressure: 0.05–0.9 MPa
- Temperature range: -20℃ to 80℃
- Medium: Dry air (ISO8573-1:2010 Class 3)
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting: Standard female thread (M6×1.0 mounting holes)
- Magnetic coupling type: External non-contact magnetic transmission
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500–800 mm/s (load dependent)
- Port size: M5×0.8 (Rc1/8 adapter optional)
- Seal material: HNBR with wear-resistant ring
- Protection rating: IP54 (standard) / IP67 (optional wiper kit)
- Weight: 2.8 kg (excluding accessories)
- Dimensions:
- Total length: 930mm (stroke + end caps)
- Body diameter: Ø20mm ±0.1mm
- Mounting height: 40mm (from base to center axis)
- Slider width: 65mm
High-precision magnetic coupled rodless cylinder featuring zero leakage design through contactless power transmission. The RMSF20X750 combines extended stroke capability with corrosion-resistant aluminum alloy construction, ideal for cleanroom environments. Integrated T-slot mounting enables multi-position sensor installation for automated positioning systems.
Industrial Applications:
- High-speed packaging line transfer systems
- Precision electronic component assembly
- Automated optical inspection (AOI) equipment
- Pharmaceutical blister packaging machines
- Lithium battery production line handling
Operation guidelines:
- Horizontal mounting recommended for full-stroke applications
- Apply ISO VG32 hydraulic oil mist lubrication (0.5–1 cc/m³)
- Maintain ≤0.3mm/m parallelism between rail and slider
- Use anti-rotation brackets for vertical installations
Critical parameters:
- Maximum side load: 15N at mid-stroke
- Lubrication interval: Every 100km travel or 6 months
- Re-lubrication quantity: 1–2 drops per lubrication point
- Magnetic field safety distance: ≥50mm from sensitive electronics
| Property | Property Value |
|---|---|
| sku | RMSF20X750 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke 220mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <20mm> |
| Stroke | 750 MM |
