Airtac RMSF Magnetic Coupling Rodless Cylinder RMSF32X450
2、Piston motion is transmitted to external slider through magnetic coupling force, achieving compact installation footprint compared to standard cylinders while delivering extended stroke lengths;
3、Integrated adjustable cushioning at both ends with fixed buffer devices enables smooth directional switching without impact shocks, effectively preventing mechanical wear;
4、Isolated piston chamber and slider configuration creates contamination-resistant structure, blocking dust ingress to significantly enhance operational lifespan.
Category: Rodless Cylinders , Brand: AirTAC , Series: RMSF
AirTAC RMSF32X450 Magnetic Coupled Rodless Cylinder Specifications
- Model: RMSF32X450
- Type: ISO 15552 compliant magnetic coupled rodless cylinder
- Bore size: 32mm
- Stroke length: 450mm (±1mm tolerance)
- Operating pressure: 0.1–0.8 MPa
- Max theoretical thrust: 201N (at 0.6MPa)
- Piston speed: 50–800 mm/s (cushioned)
- Temperature range: -20℃ to 80℃
- Mounting style: Side-mount (standard), flange mount optional
- Sensor slots: 2x T-slot for magnetic switches (SM-6 compatible)
- Seal material: NBR/PU composite seals
- Weight: 3.8kg (excluding mounting accessories)
- Dimensions: 700mm(L) × 80mm(W) × 50mm(H) (full extension)
- Repeat positioning accuracy: ±0.5mm
- Corrosion resistance: ISO 9227 salt spray test 72h compliant
High-precision rodless cylinder with magnetic coupling technology eliminating external seals. Features integrated T-slots for position feedback and dual adjustable pneumatic cushions. The stainless steel band seal system prevents contamination ingress while maintaining zero leakage. Requires filtered air (5-50μm) with ISO 8573-1:2010 Class 3 purity.
- Pick-and-place automation in cleanroom environments
- Linear material handling in packaging lines
- Precision alignment systems for LCD panel manufacturing
- Automated inspection equipment with position feedback
- Overhead conveyor systems requiring space optimization
Installation protocol:
Maintain 0.05mm/m alignment tolerance during mounting. Apply Molykote 111 lubricant
to slide rails during assembly. Magnetic switches require 3-5mm gap adjustment
from cylinder axis. Avoid lateral loading >10% of max thrust capacity.
| Property | Property Value |
|---|---|
| sku | RMSF32X450 |
| Mounting Type | Without Mounting Accessories |
| Safety Holding Force N | Stroke: 560mm |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20-70°F Speed Range: 50-400 mm/s |
| Port Size | PT1/8 |
| Bore Diameter | <32 mm> |
| Stroke | 450mm |
