Airtac S3HS Selector Mechanical Valve S3HS08GG
2. S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual actuation with multiple structural configurations of control heads for enhanced adaptability across diverse application scenarios;
3. Poppet valve structure ensures excellent sealing performance, smooth directional switching, and maintenance-free operation without lubrication requirements;
4. Multi-position mounting capability facilitates flexible integration and simplified installation;
5. S3C, S3D, S3Y, S3R, and S3L series employ metal-constructed control heads for enhanced durability, reliability, and operational stability.
Category: Mechanical Valves , Brand: AIRTAC , Series: S3HS
AirTAC S3HS08GG Selector Mechanical Valve Technical Details
- Model: S3HS08GG
- Type: 3-position selector valve (Mechanical spring return)
- Port configuration: 5 ports / 3 positions
- Port size: PT1/8 (G1/8 equivalent)
- Operating pressure: 0.05–1.0 MPa
- Max flow rate: 750 L/min (ANR)
- Actuation force: 5.5N±0.5N (manual operation)
- Body material: Die-cast aluminum alloy (anodized)
- Seal material: HNBR (Hydrogenated Nitrile)
- Temperature range: -10℃ to 80℃ (non-freezing)
- Weight: 320g ±5%
- Dimensions: 58mm(L) × 42mm(W) × 78mm(H)
- Mounting: Sub-base compatible (ISO 15407-1)
- Response time: ≤50ms (pressure-balanced design)
- Leakage: ≤20 cm³/min (at 0.5 MPa)
Multi-functional directional control valve with center closed position, featuring pressure compensation design for stable switching under variable loads. The hardened stainless steel shaft and wear-resistant seals enable 1 million+ cycle durability. Optimized flow paths reduce pressure drop by 15% compared to previous generations.
- Pneumatic fixture clamping systems
- Assembly line tooling position control
- Material handling equipment direction switching
- Textile machinery pattern selection mechanisms
- Semiconductor wafer handling vacuum/pressure circuits
Installation guidelines:
Install with arrow marking aligned to main flow direction.
Use thread sealant on male ports (PT) or flat washers for G-thread.
For vertical mounting, ensure exhaust ports face downward to prevent debris ingress.
| Property | Property Value |
|---|---|
| sku | S3HS08GG |
| Position | 3-Port 2-Position |
| Port Size | PT1/4 |
