Airtac S3Y Rocker Arm Type Mechanical Valve S3Y06G
2. The S3PF, S3PM, S3PP, S3PL, S3Y, S3HS, S3C, and S3D series feature manual override operation with multiple ergonomic actuator head configurations for versatile application adaptability;
3. Poppet-type valve design ensures excellent sealing performance, smooth actuation, and maintenance-free operation without lubrication requirements;
4. Multi-position mounting capability enables flexible installation and simplified system integration;
5. Metal actuator heads on S3C, S3D, S3Y, S3R, and S3L series provide enhanced durability, reliability, and stable performance in demanding environments.
Category: Mechanical Valves , Brand: Airtac , Series: S3Y Rocker Arm Type
AirTAC S3Y06G Lever-Operated Mechanical Valve Specifications
- Model: S3Y06G
- Type: 3/2-way lever-operated mechanical valve (normally closed)
- Port type: G thread (ISO228/1 standard)
- Port size: G1/4 (6mm nominal)
- Operating pressure: 0.15–0.8 MPa (21.7–116 PSI)
- Max flow rate: 850 L/min (Cv=1.2)
- Actuation force: ≤3.5N (lever pressure point)
- Seal material: Nitrile Butadiene Rubber (NBR)
- Body material: Anodized aluminum alloy
- Temperature range: -5℃ to 60℃ (operating fluid)
- Weight: 215g ±5g
- Dimensions: 53mm(L) × 38mm(W) × 72mm(H)
- Mounting: Direct piping or subplate (ISO 15407-2 compatible)
- Response time: ≤50ms (mechanical actuation)
The S3Y06G features a rugged lever mechanism with 500,000+ cycle durability, designed for manual override operations or mechanical triggering in harsh environments. Its optimized flow path reduces air turbulence by 18% compared to previous generations. The valve includes a visual position indicator and dual O-ring shaft sealing for dust resistance.
- Emergency stop systems in assembly lines
- Position locking in material handling equipment
- Manual control stations for pneumatic presses
- Safety interlocks in woodworking machinery
- Actuator override in automated warehouse systems
Installation note:
Lubricate lever pivot point with silicone grease (ISO 6743-4 HLP 22)
every 6 months. Ensure lever arm has 15° minimum clearance for full
stroke operation. Use backup wrench on hex flats during port
connection to prevent body rotation.
| Property | Property Value |
|---|---|
| sku | S3Y06G |
| Position | 3-Port 2-Position |
| Port Size | PT1/8 |
