Airtac SAID100 Double Rod Cylinder SAID100AX220
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX220 Dual Rod Cylinder Specifications
- Model: SAID100AX220
- Type: Dual rod cylinder (double-piston-rod design)
- Bore size: 100 mm
- Stroke: 220 mm
- Operating pressure: 0.1–1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable air cushion at both ends
- Mounting style: Basic fixed mounting (optional flange/feet mounts)
- Port size: G1/2 (ISO standard)
- Cylinder tube material: Aluminum alloy with hard anodized surface
- Piston rod material: Chrome-plated steel (hardened)
- Rod diameter: 25 mm (both rods)
- Seal material: NBR (nitrile rubber)
- Protection rating: IP65 (standard)
- Weight: 6.8 kg (±2%)
- Dimensions (L×W×H): 560 mm × 150 mm × 150 mm (total length includes stroke)
High-rigidity dual rod cylinder engineered for precision linear motion under heavy loads. The symmetrical dual-piston-rod design eliminates rotational torque, ensuring exceptional stability in high-moment applications. Features corrosion-resistant construction, adjustable cushioning for smooth end-stroke deceleration, and hardened piston rods for wear resistance. Requires ISO 8573-1:2010 Class 3-4-3 compressed air quality.
- Precision press-fit operations in automotive assembly
- Vertical lifting systems for heavy molds
- Parallel gripper positioning in robotic arms
- Paper/web tension control in printing machinery
- Precision alignment stages in semiconductor manufacturing
Installation note:
Maintain strict parallelism (≤0.2mm/m misalignment) between rods and load path.
Use rod-end spherical bearings for angular compensation. Lubricate with ISO VG32
hydraulic oil if pneumatic oil mist lubrication isn't available.
| Property | Property Value |
|---|---|
| sku | SAID100AX220 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 220mm |
