Airtac SAID100 Double Rod Cylinder SAID100AX230
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX230 Dual Rod Cylinder Specifications
- Model: SAID100AX230
- Type: ISO 6432 standard dual-rod cylinder
- Bore size: Ø100 mm
- Stroke: 230 mm (customizable 25-500mm)
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting: AX series - front flange with through holes
- Port size: M27×2 (G3/8 optional)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile) standard
- Weight: 6.8 kg (with 230mm stroke)
- Dimensions (L×W×H): 450×200×200 mm
- Rod diameter: Ø25 mm (dual rods)
- Max theoretical force: 785 N @0.8 MPa
- Speed range: 50-750 mm/s
High-rigidity dual-piston-rod cylinder designed for applications requiring precise linear motion and moment resistance. Features symmetrical force distribution with twin chrome-plated rods, reducing lateral load stress. The anodized barrel provides corrosion resistance, while precision-machined end caps ensure leak-proof operation. Requires ISO 8573-1 air quality standard.
- Precision press mechanisms in automotive assembly
- Vertical lifting platforms with guided motion
- Glass handling systems requiring parallel movement
- Automated welding fixture positioning
- Semiconductor wafer transfer robots
Installation note:
Ensure perfect parallelism during mounting (max 0.2mm/m misalignment).
Lubricate with ISO VG32 hydraulic oil before initial operation.
Allow 20mm clearance behind stroke end for cushioning effectiveness.
| Property | Property Value |
|---|---|
| sku | SAID100AX230 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | <230 mm> |
