Airtac SAID100 Double Rod Cylinder SAID100AX240
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX240 Dual Axis Cylinder Technical Details
- Model Code: SAID100AX240
- Type: ISO 15552 compliant dual-rod cylinder
- Bore Size: Ø100 mm
- Stroke: 240 mm (adjustable cushioning)
- Operating Pressure: 0.1-0.9 MPa
- Piston Rod: Hard chrome-plated steel, Ø25mm x2 rods
- Cushioning: Adjustable air cushion (both ends)
- Port Size: G3/8 (NPT1/4 optional)
- Ambient Temperature: -20℃ to 80℃
- Seal Material: High-grade NBR + PU combination
- Mounting: Standard ISO 15552 mounting pattern
- Weight: 5.8 kg (without accessories)
- Dimensions: 340mm(L) × 120mm(W) × 120mm(H)
- Position Detection: Magnetizable (sensor not included)
- Protection Class: IP54 (standard), IP67 with optional seals
- Max Thrust: 706N @0.63MPa
Industrial-grade dual-rod cylinder designed for heavy-duty linear motion requiring exceptional rigidity and alignment precision. Features symmetrical load distribution through twin piston rods, making it ideal for applications demanding minimal deflection under high moment loads. The nickel-plated end caps and corrosion-resistant barrel ensure durability in harsh environments.
- Automated welding fixture positioning systems
- Precision press brake tooling adjustment
- Heavy material clamping in CNC machining centers
- Palletizing robot end-effector guidance
- Glass manufacturing conveyor alignment
Installation guidelines:
Always use alignment jigs during mounting to prevent rod binding.
Requires minimum 3mm PTFE-based grease coating on rods before initial operation.
Maximum allowable side load: 15% of axial thrust capacity.
Critical note:
Avoid using in high-speed applications (>1 m/s) without external shock absorbers.
For vertical installations, mandatory use of counterbalance valves required.
| Property | Property Value |
|---|---|
| sku | SAID100AX240 |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | 240mm |
