Airtac SAID100 Double Rod Cylinder SAID100AX25S
2. Patented asymmetric bidirectional sealing structure with integrated oil reservoir for compact dimensions and enhanced lubrication retention
3. H-shaped aluminum alloy barrel with rodless design improves corrosion resistance, featuring machined sensor mounting grooves for tool-free installation
4. Precision adjustable cushioning mechanism ensures smooth end-stroke deceleration
5. Available in multiple bore sizes with comprehensive mounting accessories portfolio
6. High-temperature resistant sealing materials enable extended operating range (0-150℃)
Category: Double Rod Cylinder , Brand: AirTAC , Series: SAID100
AirTAC SAID100AX25S Twin Shaft Cylinder Technical Details
- Model Code: SAID100AX25S
- Type: Twin shaft pneumatic cylinder (double rod)
- Bore size: 100mm
- Stroke: 25mm (standard), customizable up to 500mm
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable air cushion at both ends
- Mounting style: Basic front/rear flange (ISO 15552 compatible)
- Port size: G3/8 (BSPP thread)
- Piston rod thread: M16×1.5 (double-ended)
- Material:
- Tube: Hard anodized aluminum alloy
- Piston rod: Chrome-plated stainless steel (SUS304)
- End caps: Cast aluminum (black oxidation treated)
- Seals: HNBR (hydrogenated nitrile) for high temperature resistance
- Ambient temperature: -20℃ to 150℃ (with HNBR seals)
- Weight: 3.8kg ±2% (with standard stroke)
- Dimensions:
- Body diameter: Φ100mm
- Total length: 242mm (25mm stroke)
- Rod diameter: Φ20mm (each shaft)
- Mounting hole spacing: 120×120mm (rear flange pattern)
- ISO certification: Compliant with ISO 6432/15552 standards
- Protection class: IP65 (dust-tight & water jet resistant)
High-rigidity twin rod cylinder designed for precision linear motion requiring exceptional moment resistance. Features dual chromium-plated guide rods that eliminate rotational torque, making it ideal for vertical installations and heavy side load applications. The symmetric force distribution enables balanced thrust in both extension/retraction strokes. Includes wear-resistant scraper seals for particle contamination prevention.
- Automated welding fixture positioning systems
- Glass panel flipping mechanisms in LCD production lines
- Precision paper cutting machinery in printing industry
- Billet centering devices in forging presses
- Vertical lifting platforms in automotive assembly
Installation guidelines:
Use alignment jigs during mounting to ensure parallel rod movement.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Maintain 0.3-0.5mm clearance between rods and external guides.
Not recommended for high-frequency (>5Hz) reciprocating cycles.
| Property | Property Value |
|---|---|
| sku | SAID100AX25S |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Cushion Stroke | <36mm> |
| Bore Diameter | 100mm |
| Stroke | <25 mm> |
